55” SR55AA 24/7 Panel

55" 24/7 4K Panel with RS232 Control

Easily present advertising, interactive information, and focused content on a 24/7 digital monitor with an Android SoC. These screens can be installed in either landscape or portrait orientation and controlled via RS232. It is ideal for shopping malls, retail stores, restaurants, art exhibitions, rail transit, and other industries.*
*The following product is distributed by Panasonic
Add to WishlistRemove from Wishlist
55” SR55AA 24/7 Panel

Features

Meticulous Design
Versatile Installation
The SRAA Series can be installed in either landscape or portrait orientation, depending on the content you are displaying.
High Brightness and Wide Viewing Angle
The SRAA Series has a brightness level of 700 nits and a viewing angle of 178 degrees, making it perfect for most indoor settings, even in very bright rooms.
HDMI CEC Compatibility
The SRAA Series is compatible with HDMI CEC, which allows other HDMI CEC-enabled devices to communicate and control the panel.
Super Slim Bezel Design
The SRAA Series has an ultra-slim 6mm bezel all the way around the screen, so you can focus on your content, not the screen itself.
Anti-Reflective Coating
The SRAA Series has a 25% haze effect on the glass, which reduces external reflections without affecting picture quality or brightness.

Meticulous Design Versatile Installation The SRAA Series can be installed in either landscape or portrait orientation, depending on the content you are displaying. High Brightness and Wide Viewing Angle The SRAA Series has a brightness level of 700 nits and a viewing angle of 178 degrees, making it perfect for most indoor settings, even in very bright rooms. HDMI CEC Compatibility The SRAA Series is compatible with HDMI CEC, which allows other HDMI CEC-enabled devices to communicate and control the panel. Super Slim Bezel Design The SRAA Series has an ultra-slim 6mm bezel all the way around the screen, so you can focus on your content, not the screen itself. Anti-Reflective Coating The SRAA Series has a 25% haze effect on the glass, which reduces external reflections without affecting picture quality or brightness.

Specs

Photo of SR55AA

Size and Weight

Height
689mm
Width
1225mm
Depth
61.7mm
Weight
11.9kg

RS232 Control
700 nits UHD Resolution

24/7 Operation
Android 9.0 with Custom UI & Extensive Engineer Menu

HDMI Input
6mm Super Slim Even Bezel Design

Landscape & Portrait Installation Support
VESA Mounting Interface

Display

  • Screen Size (Diagonal)

    • 55”

  • Native Resolution

    • 3840 (H) ×2160 (V)

  • Aspect Ratio

    • 16:09

  • Brightness

    • 700 nit (Typ.)

  • Contrast

    • ≥1200:1

  • View Angle

    • 178°(H) / 178°(V)

  • Display Color

    • 16.7M

  • Response Time

    • 8ms

  • Operation Time (Hour/Day)

    • 24/7

  • Life Time (Light Source)

    • 50,000 Hrs (Typ.)

  • Surface Treatment

    • 25% Haze

Interface

  • HDMI IN 2.0

    • ×2 (HDMI1 ARC / HDMI 2 )

  • AV IN

    • ×1 (3.5mm Earphone )

  • USB 2.0

    • x2

  • AUDIO_OUT

    • 500mVRMS(MAX) ×1

  • RS232

    • x1

  • RJ45

    • x1

  • TF Card

    • x1

Configuration

  • CPU

    • A53*4, up to 1.5GHz

  • GPU

    • Multi Core Mali G52

  • RAM/Storage

    • 2G/16G

  • O/S

    • Android 9.0

  • LAN

    • 10/100M

  • WIFI

    • 802.11b/g/n

  • Bluetooth

    • 4.2

  • Built-in Speaker

    • 10W x 2(6Ω)

Power

  • Power Supply

    • AC 100V ~ 240V@50/60HZ

  • Power Consumption

    • 165 W

  • Power Consumption (Standby)

    • 0.6 W

Environment

  • Operation Temperature

    • 0°C~50°C

  • Operation Humidity

    • 10%~85%

  • Storage Temperature

    • -20°C~60°C

  • Storage Humidity

    • 5%~95%

Physical

  • Color/Material

    • Black/Aluminum

  • Bezel Width

    • 6mm (L/R/T/B)

  • Set Outline Dimension (W×H×D)

    • 1225×689×61.7mm

  • Package Dimension (W×H×D)

    • 1379×209×853mm

  • Set Weight

    • 11.9Kg

  • Package Weight (1 set inside)

    • 21Kg

  • VESA Mounting Interface

    • 400 x 300
