Home Theatre Audio System SC-HTB600
Add to WishlistRemove from Wishlist
NO ROOM TO ADD MORE PRODUCTS
The wishlist has already reached the maximum number of products
SC-HTB600
Cinematic Sound Experience with Dolby Atmos®
The HTB600 supports Dolby Atmos® and DTS:X™, delivering immersive surround-sound. The large subwoofer provides high output and powerful bass. Enjoy fully cinematic experiences at home.
Features
An immersive cinematic experience
With support for state-of-the-art audio formats Dolby Atmos® and DTS:X™, the sound pours in from all directions. Powerful, dynamic sound travels in 3D space to bring you inside an immersive cinematic experience.
Delivers powerful cinematic sound
The full-range speaker unit 4.5 x 10 cm in front, and the bar alone achieves a total output of 160W. With a largecapacity speaker unit, the HTB600 produces richer vocal sound.
Powerful and clear bass sound
The HTB600 uses a wireless subwoofer with total output of 200W. The port inside the woofer is aerodynamically shaped for smooth air flow, reducing vibrations while delivering a stronger, clearer bass sound.
Universal design to match your TV
The minimal design of the soundbar with ultimate simplicity blends into the surrounding space, matching the TV design. It accentuates the images and sounds for the optimal entertainment experience.
Wall-mountable design
The design achieves harmony between the TV and the wall by minimising the gap when also wall-mounting the soundbar.
A conclusion of 7°
The front of the unit has a 7° slope and the speakers face upwards. This enables listeners to feel the sound directly whether the unit is on the cabinet or mounted on the wall.
Compatible with 4K Pass Through and eARC
You can enjoy high-definition 4K HDR including Dolby Vision™* contents with no loss in image quality thanks to pass through functions. It is also compatible with eARC, so high-bit-rate audio codecs can now be sent via TV.
*Dolby and Dolby Vision are trademarks of Dolby Laboratories.
Stream your music wirelessly
The HTB600 supports Bluetooth®, so you can listen to music on your smart devices wirelessly. Playback and volume control are also as simple as pressing a button, which easily turns it into a stereo speaker.
Specs
Size and Weight
- Height
- 56mm
- Width
- 962mm
- Depth
- 120mm
- Weight
- 3.3kg
The size of the wireless subwoofer is W191 x H413 x D385 mm and its weight is approximately 8.4kg.
2.1ch Speaker System- HDMI Output (eARC)
- DTS:X™
- Wireless Subwoofer
- Wall Mountable Speaker
- Bluetooth®
- 4K HDR Pass Through
- Compatible with Dolby Vision
- Dolby Atmos®
- HDMI input
- DTS:Virtual X
- Optical input
Dynamic and Immersive Sound: Dolby Atmos®/ DTS:X™ / 360W / Wireless Subwoofer
TV Matching Design: Wall-Mountable / One Remote Control
Easy to Stream & Connect: Bluetooth®/ HDMI Input / eARC / Optical Input
Amplifier
-
Amp Type
-
2.1 ch
-
-
RMS Output Power
-
Total RMS Stereo Mode Power
-
360W
-
-
Front Speaker (Left / Right)
-
80W + 80W (1K kHz, THD 10%, 4Ω)
-
-
Subwoofer
-
200W (100 Hz, THD 10%, 3Ω)
-
-
Speaker System
-
Front Speaker (Left / Right)
-
Type
-
1 way , 1 speaker system (Bass reflex)
-
-
Speaker Unit
-
Full Range: 4.5 x 10 cm Cone Type x 2
-
-
Bass Expand
-
Bass Reflex Port
-
-
-
Subwoofer
-
Type
-
1 way , 1 speaker system (Bass reflex)
-
-
Speaker Unit
-
Woofer: 16 cm Cone Type x 1
-
-
Bass Expand
-
Bass Reflex Port
-
-
Wireless
-
Yes
-
-
Network
-
Bluetooth
-
Version
-
Bluetooth® Ver 5.0
-
-
Class
-
Class 2
-
-
Codec
-
SBC
-
-
Connectivity
-
Multi-Pairing (MAX 8 Devices)
-
-
-
WiFi
-
Standard
-
-
-
-
Frequency Band
-
-
-
-
-
Chromecast built-in
-
-
-
-
Smartphone App
-
Music Streaming App *1
-
Yes (Bluetooth)
-
-
Panasonic Music Control App *1
-
-
-
-
Terminal
-
HDMI
-
Input
-
x 1
-
-
Output
-
x 1 (eARC)
-
-
-
Audio Input
-
Optical Input
-
x 1
-
-
Coaxial Digital Input
-
-
-
-
Analog Input (Pin Jack / φ3,5)
-
-
-
-
-
Other
-
IR System Terminal
-
-
-
-
USB Port
-
x 1 (For Service Use and Customer Software Update)
-
-
LAN
-
-
-
-
Function
-
Sound Function
-
Surround
-
3D Surround / Virtual Surround
-
-
SOUND MODE
-
STANDARD, MUSIC, CINEMA, VOICE, NEWS
-
-
Bass Boost
-
Yes
-
-
Subwoofer Level Adjustment
-
Yes(5 levels)
-
-
Clear-mode Dialog
-
Yes
-
-
Dialog Level Control
-
-
-
-
Low-volume Mode
-
-
-
-
Auto Gain Control
-
-
-
-
Direct music mode with remote control
-
-
-
-
Auto LIP Synchronization with HDAVI Control
-
-
-
-
-
Decoder Function / Format
-
LPCM
-
Yes (Max 7.1ch)
-
-
Dolby Digital
-
Yes
-
-
Dolby Digital +
-
Yes
-
-
Dolby True HD
-
Yes
-
-
Dolby Atmos
-
Yes
-
-
DTS Digital Surround
-
Yes
-
-
DTS ES
-
Yes
-
-
DTS 96/24
-
Yes
-
-
DTS-HD HR
-
Yes
-
-
DTS-HD High Resolution Audio
-
Yes
-
-
DTS-HD Master Audio
-
Yes
-
-
DTS : X
-
Yes
-
-
DTS Virtual : X
-
Yes
-
-
-
HDMI Function
-
CEC
-
Yes
-
-
Audio Return Channel(for HDMI Output)*2
-
Yes(eARC)
-
-
LPCM Multi Channel Input (HDMI Input)
-
-
-
-
1080p, Deep Colour, x.v. Colour
-
Yes
-
-
4K Pass through
-
Yes
-
-
FULL HD 3D COMPATIBLE
-
Yes
-
-
HDMI UP Conversion
-
-
-
-
HDR10 Pass Through
-
Yes
-
-
HDR10+ Pass Through
-
-
-
-
Dolby Vision Pass Through
-
Yes
-
-
-
USB Function
-
Service Use
-
Yes
-
-
Customer Software Update
-
Yes
-
-
USB Host Play
-
-
-
-
Playback Format
-
-
-
-
Main Unit Setting
-
Wall Mountable
-
Yes
-
-
Matching TV Size
-
43 inch and above
-
General
-
Main Unit
-
Power Supply
-
AC 220 - 240 V, 50 Hz
-
-
Power Consumption *3 Normal Use
-
30W
-
-
Power Consumption *3 Network Standby Off
-
0.5W (approx.)
-
-
Power Consumption *3 Network Standby On
-
2W (approx.)
-
-
-
Subwoofer
-
Power Supply
-
AC 220 - 240 V, 50 Hz
-
-
Power Consumption *3 Normal Use
-
36W
-
-
Power Consumption *3 Network Standby Off
-
0.5W (approx.)
-
-
Power Consumption *3 Network Standby On
-
2W (approx.)
-
-
-
Display
-
LED(5 Digit Union Jack)
-
-
Dimmer
-
Bright/Dark/Display Off
-
-
Auto OFF
-
Yes
-
Dimension
-
Main Unit (W x H x D)
-
For table top layout
-
962 x 56 x 120 mm
-
-
For table top layout with adjustable legs
-
962 x 63 x 120 mm
-
-
For wall mount layout
-
962 x 66 x 132 mm
-
-
-
Subwoofer (W x H x D)
-
191 x 413 x 385 mm
-
Weight
-
Main Unit
-
3.3 Kg
-
-
Subwoofer
-
8.4 Kg
-
Colour
-
Black
Accessories
-
Remote Control
-
Yes
-
-
Dry Batteries for Remote Control
-
Yes
-
-
AC Cord
-
Yes (Main Unit 1.5m / Subwoofer 1.2m)
-
-
Wall Mount Bracket
-
Yes
-
-
IR System Cable
-
-
-
-
Operating Instruction
-
Yes
-
-
Quick Setting Guide
-
-
-
Note
-
*1 Available for iOS and Android. Download on the App Store. Download on Google Play™.
*2 ARC Audio Return Channel compatible TV is required.
*3 Specifications are subject to change without notice. All numbers given here are approximate.
TRADEMARK NOTICE:
-
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.
Google Play is a trademark of Google LLC.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners.
Dolby, Dolby Vision, Dolby Atmos, and the double-D symbol are trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS, Inc.
DTS, the Symbol, DTS and the Symbol together, Virtual:X, and the DTS Virtual:X logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries.
© DTS, Inc. All Rights Reserved.
