X-Premium Inverter R32 XU Series (ZKH-1)

Retail Sales Price:from RM 2,642.00

Energy Labels

Model Number	CS-XU10ZKH-1_CU-XU10ZKH-1	CS-XU13ZKH-1_CU-XU13ZKH-1	CS-XU18ZKH-1_CU-XU18ZKH-1	CS-XU24ZKH-1_CU-XU24ZKH-1
Horsepower	1.0 HP	1.5 HP	2.0 HP	2.5 HP
Energy Efficiency Label

X-Premium Inverter XU Series (ZKH-1)

Purify Around-the-Clock with nanoe™ X

Panasonic X-Premium Inverter XU Series (ZKH-1) integrates nanoe™ X technology with nanoe X Generator Mark 3 for faster pollutant inhibition, while the improved Inside Cleaning cleans and dries the inside of the indoor unit. Built-In Easy Connect allows easier and faster Wi-Fi connectivity to Panasonic Comfort Cloud App. Enjoy comfortable cooling with AEROWINGS, and advanced humidity control with Dry Mode and iAUTO-X with Humidity Sensor. Achieve energy efficiency without compromising comfort with Inverter technology, R32 refrigerant, and ECO Mode with A.I. Control.

Please Select Your User Type

X-Premium Inverter XU Series (ZKH-1)

Retail Sales Price:from RM 2,642.00

Features

Stay Safe Indoors with 24-hour nanoe™ X Air Protection

nanoe™ X technology with the benefits of hydroxyl radicals effectively inhibits adhered and airborne pollutants while reducing frequently encountered odours for clean and fresh air. nanoe™ X mode can be switched ON independently (without cooling operation) with low energy consumption at 25W/hour* to continually purify your living spaces, providing a cleaner and comfortable space for you and your loved ones - making your home a safe haven 24/7.

LEARN MORE

*Energy consumption may vary depending on models.

Clean and Fresh Environment Every Day

New nanoe X Generator Mark 3*

Equipped with the latest nanoe X Generator Mark 3 to offer greater effectiveness in inhibiting various pollutants and deodorising odours at a faster pace compared to the previous nanoe X Generator Mark 2.

*The content of this page is specific to residents of Malaysia.
*Testing organisation: Shokukanken, Inc. Test subject: Adhered MS2 Phage Virus. Test volume: Approx. 25m³ laboratory. Test result: Inhibited 99.99% in 2 hours.
Test Report No.: 227131N

LEARN MORE

Inside Cleaning On Demand

The newly improved inside cleaning function can be activated on a need basis. It works inside of an indoor unit to remove moisture, and release nanoe™ X particles, inhibiting various pollutants while ensuring that the inside of the indoor unit is always dry and clean.

Effective in Removing 99% of Dust Particles

Effective in removing 99% of dust particles*, nanoe-G releases negative ions to capture dust particles as small as PM2.5, carrying them back to the filter to provide a cleaner indoor environment.

*Testing organisation: FCG Research Institute, Inc. Testing method: nanoe-G-equipped air conditioner was operated and tested in a 23m³ sized test room.
Test result: Removed 99% of particles in 202 minutes (compared to the initial concentration). (25034) Not a result of experiments in an actual use environment. Results may vary based on usage, and seasonal and environmental variables (temperature and humidity).

LEARN MORE

Effective in Removing 99% of Dust Particles

Connect & Control Your Air Conditioners Anywhere, Anytime

With the built-in Wi-Fi and Panasonic Comfort Cloud App, connect and control multiple air conditioning units from anywhere, at home or away.

LEARN MORE

Connectivity and Control, Simplified

Monitor Energy Consumption

Monitoring usage of air conditioning units using comprehensive energy statistics, and identifying issues with error notifications for effortless troubleshooting.

Secured & Easier Setup with Advanced Scan Connectivity*

Scan the QR code to enable easier and faster Wi-Fi connectivity to the air conditioner.

*Complied with internal cybersecurity guidelines based on cybersecurity trends and the regulations of each country.
Note: The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic is under license. Other trademarks and trade names are those of their respective owners.

Secured & Easier Setup with Advanced Scan Connectivity*

Better Living, Together with Energy-saving and Eco-friendly Technologies

Inverter technology helps to save on energy bills without compromising comfort, reducing energy consumption significantly compared to non-Inverter. Panasonic’s Inverter technology uses a micro-computer with compressor to precisely control temperature, providing a comfortable environment while saving energy.

LEARN MORE

*Comparison of 2.0HP STANDARD NON-INVERTER R32 and 2.0HP X-PREMIUM INVERTER R32.
*Annual energy consumption value based on tested result.
*Electricity bill calculated is based on [annual energy consumption value x Malaysia electricity tariff (0.218kWh/h)]
*Savings is different depends on model selected and annual energy consumption.

INVERTER SAVING CALCULATOR

Intelligently Balances Energy Savings and Comfort

Every space has a different temperature and it varies throughout the day. ECO Mode with Artificial Intelligence (A.I.) Control learns and judges the optimal ECO level to maximise energy savings up to 20%* while providing consistent cooling comfort.

*Comparison of ECO mode & normal mode by using 1.5HP Inverter Model.

LEARN MORE

Intelligently Balances Energy Savings and Comfort

Humidity Control for Better Comfort

Humidity Sensor Optimises an Ideal Indoor Environment

iAUTO-X together with built-in Humidity Sensor constantly monitors and adjusts relative humidity levels to below 60% for an optimal indoor environment, so you can enjoy comfortable cooling all day long.

LEARN MORE

Humidity Sensor Optimises an Ideal Indoor Environment

Remove Excess Moisture with Dry Mode and Humidity Sensor

Dry Mode together with built-in Humidity Sensor accurately detects and adjusts the humidity level in the room to below 55%, removing excess moisture to maintain the comfort level of its occupants.

Healthy Airflow for Your Cooling Comfort

Up to 15 Meters Long Air Distance with AEROWINGS

AEROWINGS provides long air distance as far as 15 meters* by incorporating two independently controlled flaps, so you can enjoy the cooling sensation even if you are across the room.

*Tested 15 meters long airflow based on X-PREMIUM INVERTER.

LEARN MORE

Up to 15 Meters Long Air Distance with AEROWINGS

Faster Cooling with iAUTO-X

iAUTO-X provides 25%* faster cooling through the use of Panasonic Thermal Enhancement Technology (P-TECh) which enables the compressor to achieve maximum frequency quickly from start-up, allowing you to relish the cooling comfort instantly, even on a scorching hot day. This feature can also be reactivated whenever the room is getting warmer due to the increase of occupants in it, keeping everyone comfortable at all times.

*Comparison of iAUTO-X mode & normal COOL mode by using 1.5HP X-PREMIUM INVERTER Model.

LEARN MORE

Range

Model
Horsepower		1.0	1.5	2.0	2.5
Cooling Capacity	kW	2.80	3.66	5.57	6.60
Cooling Capacity	Btu/h	9,550	12,500	19,000	22,500
Indoor Unit		CS-XU10ZKH-1	CS-XU13ZKH-1	CS-XU18ZKH-1	CS-XU24ZKH-1
Outdoor Unit		CU-XU10ZKH-1	CU-XU13ZKH-1	CU-XU18ZKH-1	CU-XU24ZKH-1
Retail Sales Price		RM 2,642.00	RM 3,471.00	RM 4,770.00	RM 5,671.00

Specs

CS-XU10ZKH-1_CU-XU10ZKH-1

CS-XU13ZKH-1_CU-XU13ZKH-1

CS-XU18ZKH-1_CU-XU18ZKH-1

CS-XU24ZKH-1_CU-XU24ZKH-1

nanoe X Generator Mark 3
Inside Cleaning On Demand
Built-In Easy Connect
MyHIJAU
Dry Mode with Humidity Sensor
iAUTO-X with Humidity Sensor
nanoe-G
AEROWINGS
Inverter
ECO Mode with A.I. Control
R32 Refrigerant

nanoe™ X 24-hour protection inhibits various pollutants and deodorises odours

Inside Cleaning On Demand ensures the inside of the indoor unit is pollutant-free

Manage your air conditioner using your mobile device with Comfort Cloud App

Advanced humidity control operated by Dry Mode and iAUTO-X with built-in Humidity Sensor

15 meters long air distance with AEROWINGS

Energy efficiency with ECO Mode with A.I. Control, Inverter and environmentally friendly R32 refrigerant

	CS-XU10ZKH-1_CU-XU10ZKH-1	CS-XU13ZKH-1_CU-XU13ZKH-1	CS-XU18ZKH-1_CU-XU18ZKH-1	CS-XU24ZKH-1_CU-XU24ZKH-1
Cooling Capacity (min-max) (kW)	2.80 (0.92-3.60) kW	3.66 (1.02-4.20) kW	5.57 (1.10-6.21) kW	6.60 (1.12-7.18) kW
Cooling Capacity (min-max) (Btu/h)	9,550 (3,140-12,300) Btu/h	12,500 (3,480-14,300) Btu/h	19,000 (3,750-21,200) Btu/h	22,500 (3,820-24,500) Btu/h
EER (min-max) (Btu/hW)	13.64 (13.96-11.28) Btu/hW	13.16 (13.92-12.12) Btu/hW	13.01 (13.89-12.47) Btu/hW	12.23 (12.32-11.95) Btu/hW
EER (min-max) (W/W)	4.00 (4.09-3.30) W/W	3.85 (4.08-3.56) W/W	3.82 (4.07-3.65) W/W	3.59 (3.61-3.50) W/W
CSPF (W/W)	6.45 W/W	6.43 W/W	7.09 W/W	6.21 W/W
Voltage (V)	230 V	230 V	230 V	230 V
Current (A)	3.3 A	4.2 A	6.5 A	8.3 A
Power Input (min-max) (W)	700 (225-1,090) W	950 (250-1,180) W	1,460 (270-1,700) W	1,840 (310-2,050) W
Moisture Removal (L/h)	1.6 L/h	2.1 L/h	3.0 L/h	3.7 L/h
Moisture Removal (Pt/h)	3.4 Pt/h	4.4 Pt/h	6.3 Pt/h	7.8 Pt/h
Indoor Unit Air Circulation	11.8 m³/min (415 ft³/min)	12.5 m³/min (440 ft³/min)	18.7 m³/min (660 ft³/min)	19.2 m³/min (680 ft³/min)
Indoor Unit Noise Level (H / L / Q-Lo)	38/26/19 dB(A)	40/28/19 dB(A)	44/32/27 dB(A)	45/34/28 dB(A)
Indoor Unit Dimensions (H x W x D) (mm)	295 mm x 870 mm x 229 mm	295 mm x 870 mm x 229 mm	295 mm x 1,040 mm x 244 mm	295 mm x 1,040 mm x 244 mm
Indoor Unit Dimensions (H x W x D) (inch)	11-5/8 inch x 34-9/32 inch x 9-1/32 inch	11-5/8 inch x 34-9/32 inch x 9-1/32 inch	11-5/8 inch x 40-31/32 inch x 9-5/8 inch	11-5/8 inch x 40-31/32 inch x 9-5/8 inch
Indoor Unit Net Weight	10 kg (22 lb)	10 kg (22 lb)	12 kg (26 lb)	12 kg (26 lb)
Outdoor Unit Air Circulation	27.6 m³/min (970 ft³/min)	30.9 m³/min (1,090 ft³/min)	34.9 m³/min (1,230 ft³/min)	34.9 m³/min (1,230 ft³/min)
Outdoor Unit Noise Level (H / L / Q-Lo)	47 dB(A)	48 dB(A)	50 dB(A)	52 dB(A)
Outdoor Unit Dimensions (H x W x D) (mm)	511 mm x 650 mm x 230 mm	542 mm x 780 mm x 289 mm	619 mm x 824 mm x 299 mm	619 mm x 824 mm x 299 mm
Outdoor Unit Dimensions (H x W x D) (inch)	20-1/8 inch x 25-19/32 inch x 9-1/16 inch	21-11/32 inch x 30-23/32 inch x 11-13/32 inch	24-3/8 inch x 32-15/32 inch x 11-25/32 inch	24-3/8 inch x 32-15/32 inch x 11-25/32 inch
Outdoor Unit Net Weight	17 kg (37 lb)	22 kg (49 lb)	30 kg (66 lb)	31 kg (68 lb)
Refrigerant Pipe Diameter (Liquid Side)	ø 6.35 mm (1/4 inch)	ø 6.35 mm (1/4 inch)	ø 6.35 mm (1/4 inch)	ø 6.35 mm (1/4 inch)
Refrigerant Pipe Diameter (Gas Side)	ø 9.52 mm (3/8 inch)	ø 9.52 mm (3/8 inch)	ø 12.70 mm (1/2 inch)	ø 12.70 mm (1/2 inch)
Pipe Extension (Chargeless Pipe Length)	7.5 m	7.5 m	10 m	10 m
Pipe Extension (Maximum Pipe Length)	20 m	20 m	30 m	30 m
Pipe Extension (Maximum Elevation Length)	15 m	15 m	20 m	20 m
*Pipe Extension (Additional Refrigerant Gas)**	10 g/m	10 g/m	15 g/m	15 g/m
Power Supply	Indoor	Indoor	Indoor	Indoor
iAUTO-X	Yes	Yes	Yes	Yes
iAUTO-X with Humidity Sensor	Yes	Yes	Yes	Yes
Dry Mode with Humidity Sensor	Yes	Yes	Yes	Yes
ECO Mode with A.I.	Yes	Yes	Yes	Yes
Inverter Control	Yes	Yes	Yes	Yes
Sleep Mode	Yes	Yes	Yes	Yes
Quiet Mode	Yes	Yes	Yes	Yes
Soft Dry Operation Mode	Yes	Yes	Yes	Yes
Personal Airflow Creation	Yes	Yes	Yes	Yes
nanoe™ X	Yes (Generator Mark 3)	Yes (Generator Mark 3)	Yes (Generator Mark 3)	Yes (Generator Mark 3)
Inside Cleaning On Demand	Yes	Yes	Yes	Yes
nanoe-G	Yes	Yes	Yes	Yes
Odour Removing Function	Yes	Yes	Yes	Yes
Removable Washable Panel	Yes	Yes	Yes	Yes
24-Hour Dual ON & OFF Real Setting Timer	Yes	Yes	Yes	Yes
LCD Wireless Remote Control	Yes	Yes	Yes	Yes
Wireless LAN Remote Control (For Internet Connection)	Yes (Built-in)	Yes (Built-in)	Yes (Built-in)	Yes (Built-in)
Wired Remote Control	Yes (Optional)	Yes (Optional)	Yes (Optional)	Yes (Optional)
Random Auto Restart	Yes (32 Restart Patterns)	Yes (32 Restart Patterns)	Yes (32 Restart Patterns)	Yes (32 Restart Patterns)
Blue Fin Condenser	Yes	Yes	Yes	Yes
Long Piping (max.)	20 m	20 m	30 m	30 m
Top Panel Maintenance Access	Yes	Yes	Yes	Yes
Self-Diagnostic Function	Yes	Yes	Yes	Yes
Note	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.

Documents

Panasonic Air Conditioner X-Premium Inverter R32 (ZKH-1) Leaflet (PDF - 9.7 MB)

Combination

Optional Individual Controller

CZ-RD514C

Wired remote for wall mounted air conditioners. It supports basic AC operations and timer control.

Optional Centralised Controller (Connecting Adaptor Required)

CZ-64ESMC3

Efficient management with centralised control of up to 64 units (64 groups, 64 indoor units). This solution includes four energy-saving functions, demand control, and timer functions, all designed to improve overall management efficiency.

CZ-ANC3

Enable simple, centralised control of up to 64 units (16 groups, 64 indoor units). This system specialises in ON/OFF control for easy and efficient management.

CZ-256ESMC3

Control up to 256 indoor units* centrally, promoting comfort and energy efficiency across the building with four energy-saving functions and demand control. The system offers swift AC cost calculations for tenants and enables remote monitoring and control via the internet.

CZ-CFUSCC1

AC Smart Cloud communication adaptor. Control up to 128 groups (128 indoor units) with ease.

CZ-CSWKC2

P-AIMS (Panasonic - Air Conditioning Intelligent Management System) integrates monitoring and control of air conditioners from your PC. By coupling basic software with optional ones, it enables comprehensive monitoring and control of all types of building equipment.
