Smart Inverter LU Series (AKH-1)

Retail sales price:from RM 2,200.00

Where to Buy

Energy Labels

Model Number	CS-LU9AKH-1_CU-RU9AKH	CS-LU12AKH-1_CU-RU12AKH	CS-LU18AKH-1_CU-RU18AKH-B	CS-LU24AKH-1_CU-RU24AKH
Horsepower	1.0 HP	1.5 HP	2.0 HP	2.5 HP
Energy Efficiency Label

Smart Inverter LU Series (AKH-1)

Smarter Cooling, Sustainable Savings

The Panasonic Smart Inverter LU Series (AKH-1) features built-in Wi-Fi, allowing you to manage your air conditioner from anywhere using the Panasonic Comfort Cloud App on your mobile device. Achieve energy efficiency without compromising comfort with Inverter technology and ECO Mode with A.I. Control. Enjoy powerful cooling instantly with just a push of the POWERFUL mode button. BIG FLAP/AEROWINGS* directs airflow further across the room. Equipped with R32 refrigerant, an environmentally friendly choice.

*BIG FLAP is applicable to CS-LU9AKH-1 and CS-LU12AKH-1. AEROWINGS is applicable to CS-LU18AKH-1 and CS-LU24AKH-1.

Please Select Your User Type

Smart Inverter LU Series (AKH-1)

Retail sales price:from RM 2,200.00

SHOP NOW

Where to Buy

Features

Connect & Control Your Air Conditioners Anywhere, Anytime

With the built-in Wi-Fi and Panasonic Comfort Cloud App, connect and control multiple air conditioning units from anywhere, at home or away.

LEARN MORE

Connectivity and Control, Simplified

Monitor Energy Consumption

Monitoring usage of air conditioning units using comprehensive energy statistics, and identifying issues with error notifications for effortless troubleshooting.

Secured & Easier Setup with Advanced Scan Connectivity*

Scan the QR code to enable easier and faster Wi-Fi connectivity to the air conditioner.

*Complied with internal cybersecurity guidelines based on cybersecurity trends and the regulations of each country.
Note: The Bluetooth^® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic is under license. Other trademarks and trade names are those of their respective owners.

Cool Efficiency, Energy-Saving with Inverter Technology

Panasonic air conditioners deliver excellent energy efficiency, harnessing the power of Inverter technology. Panasonic's Inverter technology utilises a micro-computer to control a variable-speed compressor, ensuring precise temperature control and minimising energy consumption while maintaining a balanced comfort level. Choose the smarter, greener option with Inverter techonology, and enjoy both lower bills and a reduced environmental impact.

LEARN MORE

Note: Up to 52% energy savings based on the comparison of the 2.5HP Smart Inverter model with the lowest 2-star model. Actual savings may vary depending on model and usage.

Intelligently Balances Energy Savings and Comfort

Every space has a different temperature and it varies throughout the day. ECO Mode with Artificial Intelligence (A.I.) Control learns and judges the optimal ECO level to maximise energy savings up to 20%* while providing consistent cooling comfort.

*Comparison of ECO mode & normal mode by using 1.5HP Inverter Model.

LEARN MORE

Comfort Cooling Environment for Your Needs

Long Airflow with Big Flap

Big bottom flap directs cooling and comforting air across the room for an optimal cooling sensation.

*Applicable to CS-LU9AKH-1 and CS-LU12AKH-1 only.

Stay Cool with Faster, Further Airflow

AEROWINGS concentrates cool air for further and faster airflow across the room using 2 flaps. The sub-flap compresses and concentrates cool air, while the outer flap helps to deliver airflow further.

*Applicable to CS-LU18AKH-1 and CS-LU24AKH-1 only.

Instant Powerful Cooling with a Push of a Button

POWERFUL mode cools your room faster by 18%*, running both the compressor and indoor fan at super high speed for you to enjoy instant powerful cooling during start-up.

*Comparison of POWERFUL cool mode & normal cool mode by using 1.5HP Inverter Model.

LEARN MORE

Calm and Peaceful Environment with Quiet Mode

Loud noises can be bothersome. Switch on Quiet mode to reduce the noise level of the indoor unit. In Quiet mode, the fan speed is reduced to minimum. This mode is ideal when you require a quiet, peaceful environment, during rest time or study.

Sleep Better at Night

A comfortable environment is essential for healthy sleep. Our body’s temperature decreases while we sleep, thus less cooling is required. Sleep mode offers ambient temperature by automatically shifting the set temperature during sleeping time.

Wireless Remote Controller

The handheld wireless remote controller is easy to use, with commonly used functions for quick access.

*A wireless remote controller is included in the same package as the indoor unit. Product design may vary by models.

Optional Wired Remote Controller

The optional wired remote controller (CZ-RD514C) provides a large display for improved visibility and a vast range of information to ease operations.

Range

Model
Horsepower	1.0 HP	1.5 HP	2.0 HP	2.5 HP
Cooling Capacity	2.65 kW	3.52 kW	5.30 kW	6.25 kW
Cooling Capacity	9,040 Btu/h	12,000 Btu/h	18,100 Btu/h	21,300 Btu/h
Indoor Unit	CS-LU9AKH-1	CS-LU12AKH-1	CS-LU18AKH-1	CS-LU24AKH-1
Outdoor Unit	CU-RU9AKH	CU-RU12AKH	CU-RU18AKH-B	CU-RU24AKH
Retail Sales Price	RM 2,200.00	RM 2,668.00	RM 4,390.00	RM 4,524.00

Specs

CS-LU9AKH-1_CU-RU9AKH

CS-LU12AKH-1_CU-RU12AKH

CS-LU18AKH-1_CU-RU18AKH-B

CS-LU24AKH-1_CU-RU24AKH

Built-In Easy Connect
My HIJAU
POWERFUL Mode
Inverter
ECO Mode with A.I. Control
BIG FLAP
AEROWINGS
R32 Refrigerant
Quiet Mode
Sleep Mode

Manage air conditioner using mobile device with Built-in Wi-Fi and Comfort Cloud App

Energy savings with Inverter Technology

POWERFUL mode lets you enjoy instant powerful cooling during start-up

Intelligently balances energy savings and comfort using ECO Mode with A.I. Control

BIG FLAP/AEROWINGS directs airflow further across the room (Applicable to selected models)

Quiet mode reduces the noise level of the indoor unit for a quiet, peaceful environment

	CS-LU9AKH-1_CU-RU9AKH	CS-LU12AKH-1_CU-RU12AKH	CS-LU18AKH-1_CU-RU18AKH-B	CS-LU24AKH-1_CU-RU24AKH
Cooling Capacity (min-max) (kW)	2.65 (0.90-3.40) kW	3.52 (1.02-4.10) kW	5.30 (1.10-6.00) kW	6.25 (1.12-7.18) kW
Cooling Capacity (min-max) (Btu/h)	9,040 (3,070-11,600) Btu/h	12,000 (3,480-14,000) Btu/h	18,100 (3,750-20,500) Btu/h	21,300 (3,820-24,500) Btu/h
EER (min-max) (Btu/hW)	12.05 (13.64-11.26) Btu/hW	11.65 (12.65-11.11) Btu/hW	11.24 (12.93-11.20) Btu/hW	11.83 (15.28-11.78) Btu/hW
EER (min-max) (W/W)	3.53 (4.00-3.30) W/W	3.42 (3.71-3.25) W/W	3.29 (3.79-3.28) W/W	3.47 (4.48-3.45) W/W
CSPF (W/W)	5.57 W/W (5★)	5.41 W/W (5★)	5.91 W/W (5★)	5.99 W/W (5★)
Voltage (V)	220-240 V	220-240 V	220-240 V	220-240 V
Current (A)	3.7-3.4 A	4.8-4.4 A	7.4-6.8 A	8.3-7.6 A
Power Input (min-max) (W)	750 (225-1,030) W	1,030 (275-1,260) W	1,610 (290-1,830) W	1,800 (250-2,080) W
Moisture Removal (L/h)	1.6 L/h	2.0 L/h	2.9 L/h	3.5 L/h
Moisture Removal (Pt/h)	3.4 Pt/h	4.2 Pt/h	6.1 Pt/h	7.4 Pt/h
Indoor Unit Air Circulation	10.3 m³/min (365 ft³/min)	11.0 m³/min (390 ft³/min)	19.3 m³/min (680 ft³/min)	19.9 m³/min (700 ft³/min)
Indoor Unit Noise Level (H / L / Q-Lo)	38/26/19 dB(A)	40/26/21 dB(A)	44/32/27 dB(A)	45/34/29 dB(A)
Indoor Unit Dimensions (H x W x D) (mm)	290 mm x 765 mm x 214 mm	290 mm x 765 mm x 214 mm	295 mm x 1,060 mm x 249 mm	295 mm x 1,060 mm x 249 mm
Indoor Unit Dimensions (H x W x D) (inch)	11-7/16 inch x 30-1/8 inch x 8-7/16 inch	11-7/16 inch x 30-1/8 inch x 8-7/16 inch	11-5/8 inch x 41-3/4 inch x 9-13/16 inch	11-5/8 inch x 41-3/4 inch x 9-13/16 inch
Indoor Unit Net Weight	8 kg (18 lb)	8 kg (18 lb)	12 kg (26 lb)	12 kg (26 lb)
Indoor Unit Gross Weight	9 kg (20 lb)	9 kg (20 lb)	15 kg (33 lb)	15 kg (33 lb)
Outdoor Unit Air Circulation	26.7 m³/min (940 ft³/min)	30.6 m³/min (1,080 ft³/min)	39.3 m³/min (1,390 ft³/min)	34.9 m³/min (1,230 ft³/min)
Outdoor Unit Noise Level (H)	47 dB(A)	48 dB(A)	50 dB(A)	51 dB(A)
Outdoor Unit Dimensions (H x W x D) (mm)	511 mm x 650 mm x 230 mm	542 mm x 780 mm x 289 mm	619 mm x 824 mm x 299 mm	619 mm x 824 mm x 299 mm
Outdoor Unit Dimensions (H x W x D) (inch)	20-1/8 inch x 25-19/32 inch x 9-1/16 inch	21-11/32 inch x 30-23/32 inch x 11-13/32 inch	24-3/8 inch x 32-15/32 inch x 11-25/32 inch	24-3/8 inch x 32-15/32 inch x 11-25/32 inch
Outdoor Unit Net Weight	18 kg (40 lb)	22 kg (49 lb)	29 kg (64 lb)	32 kg (71 lb)
Outdoor Unit Gross Weight	20 kg (44 lb)	25 kg (55 lb)	32 kg (71 lb)	35 kg (77 lb)
Refrigerant Type	R32	R32	R32	R32
Refrigerant Amount	410 g	450 g	710 g	35 kg (77 lb)
Refrigerant Pipe Diameter (Liquid Side)	ø 6.35 mm (1/4 inch)	ø 6.35 mm (1/4 inch)	ø 6.35 mm (1/4 inch)	ø 6.35 mm (1/4 inch)
Refrigerant Pipe Diameter (Gas Side)	ø 9.52 mm (3/8 inch)	ø 9.52 mm (3/8 inch)	ø 12.70 mm (1/2 inch)	ø 12.70 mm (1/2 inch)
Pipe Extension (Chargeless Pipe Length)	7.5 m	7.5 m	10 m	10 m
Pipe Extension (Maximum Pipe Length)	20 m	20 m	30 m	30 m
Pipe Extension (Maximum Elevation Length)	15 m	15 m	20 m	20 m
*Pipe Extension (Additional Refrigerant Gas)**	10 g/m	10 g/m	15 g/m	15 g/m
Power Supply	Indoor	Indoor	Indoor	Indoor
Odour Removing Function	Yes	Yes	Yes	Yes
Removable, Washable Panel	Yes	Yes	Yes	Yes
Wi-Fi	Built-in (Easy Connect)	Built-in (Easy Connect)	Built-in (Easy Connect)	Built-in (Easy Connect)
24-Hour Dual ON & OFF Real Setting Timer	Yes	Yes	Yes	Yes
LCD Wireless Remote Control	Yes	Yes	Yes	Yes
Wired Remote Control	Optional	Optional	Optional	Optional
Powerful Mode	Yes	Yes	Yes	Yes
Sleep Mode	Yes	Yes	Yes	Yes
Quiet Mode	Yes	Yes	Yes	Yes
Soft Dry Operation Mode	Yes	Yes	Yes	Yes
Airflow Direction Control (Up & Down)	Yes	Yes	Yes	Yes
Manual Horizontal Airflow Direction Control	Yes	Yes	Yes	Yes
Inverter Control	Yes	Yes	Yes	Yes
ECO Mode with A.I.	Yes	Yes	Yes	Yes
Random Auto Restart	Yes (32 Restart Patterns)	Yes (32 Restart Patterns)	Yes (32 Restart Patterns)	Yes (32 Restart Patterns)
Blue Fin Condenser	Yes	Yes	Yes	Yes
Long Piping (maximum)	20 m	20 m	30 m	30 m
Top Panel Maintenance Access	Yes	Yes	Yes	Yes
Self-Diagnostic Function	Yes	Yes	Yes	Yes
Note	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.	*When pipes are not extended from the chargeless pipe length, the required amount of refrigerant is already in the unit. Please read the Installation Instructions carefully before installing the unit, and the Operating Instructions before using it. Specifications are subject to change without prior notice.
