LUMIX S1R Full-Frame Mirrorless Camera – Body Only
Add to WishlistRemove from Wishlist
NO ROOM TO ADD MORE PRODUCTS
The wishlist has already reached the maximum number of products
DC-S1RGN-K
Ultimate Resolution. Professional Performance.
The LUMIX S1R features a 47.3MP CMOS sensor that delivers incredibly realistic detail. Focus and image Stabilisation systems that capture each instant with stunning clarity. A body design that fluidly guides photographic intentions toward unforgettable images. With all these features and more, this full-frame mirrorless camera transports you to the world of passionate image creation.
Includes LUMIX S1R body only.
Includes LUMIX S1R body only.
Features
47.3MP CMOS Sensor with 187MP High Resolution Mode
This brand new system takes LUMIX deeper into the world of professional photographic expression. The Lumix S1R has a 47.3-megapixel full-frame CMOS sensor (36mm x 24mm), the highest resolution in its class* and supports low-light shooting at up to ISO 25600 (extendable to ISO 51200).
High Resolution Mode allows photographers in the landscape, architecture, product and still life photography fields to capture incredible 187MP files for highly detailed large format prints.
High Resolution Mode allows photographers in the landscape, architecture, product and still life photography fields to capture incredible 187MP files for highly detailed large format prints.
* As a Digital Single Lens Mirrorless Camera, as of February 1, 2019.
5-axis Dual I.S. 2
The LUMIX S1R features 5-axis Dual I.S. 2* (Image Stabilizer), allowing the use of a 7-stop slower shutter speed. ** The LUMIX S1R eliminates shake in both body and lens even at the telephoto setting. It also works in both photo and video recording, including 4K video. The astonishing power of the 5-axis Body I.S. with 5.5-stop compensation power*** corrects shake for all lenses, even those not equipped with O.I.S.
* 5 Axis Dual I.S 2 can be used with Panasonic LUMIX L-mount lenses that feature O.I.S.
** Based on the CIPA standard (Yaw/Pitch direction: focusing distance f=200 mm when S-E70200 is used).
*** Based on the CIPA standard (Yaw/Pitch direction: focusing distance f=50 mm when S-X50 is used).
** Based on the CIPA standard (Yaw/Pitch direction: focusing distance f=200 mm when S-E70200 is used).
*** Based on the CIPA standard (Yaw/Pitch direction: focusing distance f=50 mm when S-X50 is used).
Advanced AF and AI Technology
Super-fast lens and sensor communication of 480 fps and Panasonic’s DFD (Depth From Defocus) technology allow the LUMIX S1R to achieve an ultra-high-speed, high-precision AF of approximately 0.08 sec*. The S1R also boasts high-speed burst shooting at 9 fps (AFS) or 6 fps (AFC), and excels in low-light shooting, with -6EV* luminance detection performance in Low Light AF, thanks to the higher sensitivity and optimised tuning of the sensor. Advanced AI Technology detects specific subjects, like humans or fast-moving animals, and keeps tracking these subjects even when they are not facing the camera.
* 11EV, at wide-end with S-R24105 (CIPA) in LVF120 fps setting.
* At ISO100, F1.4, AFS.
* At ISO100, F1.4, AFS.
5,760k-dot Live View Finder
The class-leading Live View Finder offers the world’s highest resolution* with a 5.7 million dot OLED display that delivers a minimum time lag of less than 0.005 sec and an exceptional 10,000:1 high contrast ratio. The 2.1 million dot monitor has a tri-axial tilt design for further shooting versatility, offering superb flexibility in a variety of situations, including high and low angle shooting and portraits.
* Among full-frame Digital Single Lens Mirrorless Cameras as of February 1, 2019.
Double Memory Card Slot for Flexible Data Management
The double memory card slot is compatible with SD Memory Cards (UHS-II), XQD Memory Cards* and CFexpress Memory Cards (TypeB)**. Allocation Record mode allows you to specify the card slot to be used for recording for different image formats. This feature is also convenient for recording long videos or as a backup. Relay Recording mode relays recording to the other card slot after the first card runs out of free space during recording. Backup Recording mode records the same data to the two cards.
* Can not be used with AVCHD format. XQD is a registered trademark of Sony Corporation. The CFexpress Ver 2.0 Type B is a trademark licensed by the CompactFlash Association.
** Firmware must be updated to the latest version.
** Firmware must be updated to the latest version.
Tough, Durable Design
To be tough enough to withstand heavy field use, the camera structure is composed of a magnesium alloy full die-cast front/rear frame. Robust construction and a seal for every joint, dial, and button make the LUMIX S1R not only splash resistant and dust resistant* but also freeze resistant down to -10 degrees Celsius. The durable shutter unit will withstand around 400,000 releases.
* Dust and Splash Resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.
4K 60p/50p Video Recording
LUMIX S Series full-frame cameras offer an unequalled videography feature set, recording smooth 4K 60p/50p, as well as High Speed Video which lets you record slow motion video in 4K (maximum 60 fps/50 fps) and FHD (maximum 180 fps/150 fps). 5K 30p/25p video is also possible with a firmware update.**
The S1R is also compatible with an XLR microphone adaptor to support professional audio quality.
The S1R is also compatible with an XLR microphone adaptor to support professional audio quality.
* Maximum recording time of 15 minutes in 4K 60p/50p.
** In PIXEL/PIXEL setting. Firmware must be updated to version 1.6.
** In PIXEL/PIXEL setting. Firmware must be updated to version 1.6.
Learn More about S1R Camera Features
The LUMIX S1R full-frame mirrorless camera offers outstanding image resolution and usability for every situation.
Learn more about the LUMIX S1R photo & video shooting performance, fast & precise autofocus technology, body design & expandability, via the button below.
Learn more about the LUMIX S1R photo & video shooting performance, fast & precise autofocus technology, body design & expandability, via the button below.
Get Inspired
Specs
Size and Weight
- Height
- 110mm
- Width
- 148.9mm
- Depth
- 96.7mm
- Weight
- 1016g
All values are approximate. Weight with SD card and battery (Weight with XQD card and battery is 1,020g). Lens is excluded. Dimensions exclude protrusions.
L-Mount- 47.3 Megapixels
- 4K Video Recording Capability
- 6K PHOTO
- 5-Axis Dual I.S. 2 (Image Stabilizer)
- 5760k-dot OLED Live View Finder
- 2,100k-dot Triaxial Tilt Monitor
- Status LCD
- Splash, Dust and Freeze-resistant
- Wi-Fi
- Bluetooth
47.3MP Full-Frame CMOS sensor, 187MP High Resolution Mode
5K 30p/25p/24p high-resolution video and 4K 60p/50p smooth video recording
5,760k-dot Ultra High Resolution Real View Finder
Fast and Precise Autofocus with DFD and AI Technology, -6EV Low Light AF
TYPE
-
Type
-
Digital Single Lens Mirrorless camera
-
-
Recording media
-
XQD Memory Card, SD Memory Card / SDHC Memory Card* / SDXC Memory Card*, CFexpress Card (CFexpress Ver2.0 Type B) ******
*Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.
-
-
Lens mount
-
L-Mount
-
IMAGE SENSOR
-
Type
-
35mm full-frame (36.0 x 24.0mm) CMOS sensor
-
-
Camera effective pixels / Total pixels
-
47.30 megapixels / 50.44 megapixels
-
-
Aspect ratio / Colour filter
-
3:2 / Primary color filter
-
-
Dust reduction system
-
Supersonic wave filter
-
STILL IMAGE
-
Aspect ratio
-
4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1
-
Aspect ratio
-
4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1
-
-
-
Image quality
-
RAW / RAW+Fine / RAW+Standard / Fine / Standard
-
-
Colour Space
-
sRGB, AdobeRGB
-
-
Recording file format
-
Still image
-
JPEG (DCF, Exif 2.31), RAW, HLG Photo (CTA-2072)
-
-
6K PHOTO** / 4K PHOTO**
-
6K PHOTO: MP4 (H.265/HEVC, Audio format: AAC (2ch))
4K PHOTO: MP4 (H.264/MPEG-4 AVC, Audio format: AAC (2ch))
Extracted still images: JPEG (DCF, Exif 2.31)
-
-
-
File size(Pixels)
-
When using full-frame lenses / 3:2
-
8368x5584(L) / 5952x3968(M) / 4272x2848(S) / 16736x11168(XL)* *High Resolution Mode. RAW file.
5184x3456(6K PHOTO) / 3504x2336(4K PHOTO) / 6464x4320(HLG PHOTO, 8K-Res.) / 3232x2160(HLG PHOTO, 4K-Res.)
-
-
When using full-frame lenses / 4:3
-
7440x5584(L) / 5296x3968(M) / 3792x2848(S) / 14880x11168(XL)* *High Resolution Mode. RAW file.
4992x3744(6K PHOTO) / 3328x2496(4K PHOTO) / 5760x4320(HLG PHOTO, 8K-Res.) / 2880x2160(HLG PHOTO, 4K-Res.)
-
-
When using full-frame lenses / 16:9
-
8368x4712(L) / 5952x3352(M) / 4272x2400(S) / 16736x9424(XL)* *High Resolution Mode. RAW file.
3840x2160(4K PHOTO) / 7680x4320(HLG PHOTO, 8K-Res.) / 3840x2160(HLG PHOTO, 4K-Res.)
-
-
When using full-frame lenses / 1:1
-
5584x5584(L) / 3968x3968(M) / 2848x2848(S) / 11168x11168(XL)* *High Resolution Mode. RAW file.
2880x2880(4K PHOTO) / 4320x4320(HLG PHOTO, 8K-Res.) / 2144x2144(HLG PHOTO, 4K-Res.)
-
-
When using full-frame lenses / 65:24
-
8368x3088(L)
-
-
When using full-frame lenses / 2:1
-
8368x4184(L)
-
-
When using APS-C lenses / 3:2
-
5504x3664(L) / 3920x2608(M) / 2784x1856(S)
-
-
When using APS-C lenses / 4:3
-
4880x3664(L) / 3472x2608(M) / 2480x1856(S)
-
-
When using APS-C lenses / 16:9
-
5504x3096(L) / 3840x2160(M) / 1920x1080(S)
-
-
When using APS-C lenses / 1:1
-
3664x3664(L) / 2608x2608(M) / 1856x1856(S)
-
-
MOTION PICTURE
-
MOV******** [5K] 4992x3744 High-res audio is selectable only when using the DMW-XLR1 (sold separately).
-
29.97p, 200Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, LPCM, High-Res Audio) (PIXEL/PIXEL) *HLG is selectable.
25.00p, 200Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, LPCM, High-Res Audio) (PIXEL/PIXEL) *HLG is selectable.
23.98p, 200Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, LPCM, High-Res Audio) (PIXEL/PIXEL) *HLG is selectable.
-
VIEWFINDER
-
Type
-
OLED Live View Finder
-
-
Pixels
-
Approx. 5,760k dots
-
-
Field of view / Magnification
-
Approx. 100% / Approx. 0.78x with 50 mm lens at infinity; -1.0 m-1
-
-
Eye point / Diopter adjustment
-
Approx. 21 mm at infinity; -1.0 m-1 / -4.0 - +2.0 (dpt)
-
-
Eye sensor
-
Yes
-
-
Display speed
-
120fps / 60fps
-
-
Display time lag
-
Approx. 0.005sec
-
REAR MONITOR
-
Type
-
TFT LCD monitor with static touch control
-
-
Monitor size
-
Triaxial tilt, 3.2-inch (8.0cm), 3:2 aspect
-
-
Pixels
-
Approx. 2,100k dots
-
-
Field of view
-
Approx. 100%
-
STATUS LCD
-
STATUS LCD
-
Yes
-
FOCUS
-
Type
-
Contrast AF system
-
-
DFD technology
-
Yes
-
-
Focus mode
-
AFS (Single) / AFC (Continuous) / MF
-
-
AF mode
-
Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+* / 1-Area* / Pinpoint / Custom 1, 2, 3
(Full area touch is available) (Scalable AF frame size and flexible AF position) *Human/Animal Detection AF can be set ON or OFF.********
-
-
AF detective range
-
EV -6 - 18 (F1.4, ISO100 equivalent, AFS)
-
-
AF custom setting
-
AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction
-
-
AF assist lamp
-
Yes
-
-
AF lock
-
Set the Fn button in custom menu to AF lock
-
-
Post Focus / Focus Stacking
-
Yes / Yes
-
-
Others
-
AF-ON, Shutter AF, Half Press Release, Focus/Shutter Priority, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, AF-Point Scope Setting, AF+MF, MF Guide, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function, Touch Pad AF, Touch Shutter, Focus Switching for Vert/Hor, Focus Ring Lock, Show/Hide AF Mode
-
EXPOSURE CONTROL
-
Light metering system
-
1,728-zone multi-pattern sensing system
-
-
Light metering mode
-
Multiple / Center Weighted / Spot / Highlight Weighted
-
-
Metering range
-
EV0-18 (F2.0 lens, ISO100 equivalent)
-
-
Exposure mode
-
Program AE / Aperture Priority AE / Shutter Priority AE / Manual Exposure
-
-
ISO sensitivity (Standard Output Sensitivity)
-
Auto / 50* / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200* (Changeable to 1/3 EV step) *Extended ISO
-
-
Exposure compensation
-
1/3 EV step ±5EV (±3EV for motion picture)
-
-
AE lock
-
Set the Fn button in custom menu to AE lock
-
IMAGE STABILISATION SYSTEM
-
IMAGE STABILISATION SYSTEM
-
ここまで7/16
-
WHITE BALANCE
-
White balance
-
AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Color temperature setting 1, 2, 3, 4
-
-
White balance adjustment
-
Blue/Amber bias, Magenta/Green bias
-
-
Colour temperature setting
-
2500-10000K in 100K
-
SHUTTER
-
Type
-
Focal-plane shutter
-
-
Shutter speed
-
Still image: Bulb (Max. 30 minutes), 1/8,000 - 60
Electronic front curtain shutter: Bulb (Max. 30 minutes), 1/2,000 - 60
Electronic shutter: Bulb (Max. 60 sec), 1/16,000 - 60
Motion picture: 1/16,000 - 1/25
-
-
Shutter life
-
Approx. 400,000 images
-
-
Self timer
-
10sec, 3 images / 2sec / 10sec
-
-
Remote control
-
Remote control by DMW-RS2 (sold separately)
-
-
Silent mode / Shutter type
-
Yes / Yes (Auto / Mechanical / Electronic front curtain / Electronic / Electronic+NR)
-
BRACKET
-
AE bracket
-
3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst
-
-
Aperture Bracket
-
3, 5 or all positions in 1 EV step
-
-
Focus Bracket
-
1 to 999 images, focus steps can be set in 10 levels
-
-
White balance bracket
-
3 images in blue/amber axis or in magenta/green axis, color temperature setting
-
BURST SHOOTING
-
Number of recordable images - When using XQD memory card
-
RAW: More than 40 images
RAW+JPEG: More than 35 images
JPEG: More than 50 images
*Using a Sony Corporation XQD G Series Memory Card. Until the burst shooting speed slows. When recording is performed under the test conditions specified by Panasonic.
-
6K PHOTO** / 4K PHOTO**
-
Burst speed
-
6K PHOTO: 30 frames/sec
4K PHOTO: 60 frames/sec, 30 frames/sec
-
-
Exif information
-
Yes (Each JPEG image cropped out of the 6K/4K burst file complies with EXIF.)
-
FLASH
-
Flash type
-
TTL External Flash (sold separately)
-
-
Flash Mode
-
Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced Off *For iA only.
-
-
Flash synchronization
-
1st Curtain Sync, 2nd Curtain Sync.
-
-
Flash output adjustment
-
1/3EV step ±3EV
-
-
Synchronization speed
-
Less than 1/320 second
-
-
Wireless control
-
Yes (When using DMW-FL200L / FL360L / FL580L (sold separately)), Wireless Channel: 1ch/2ch/3ch/4ch
-
-
Flash sync socket
-
Yes
-
EXTRA TELE CONVERSION
-
EXTRA TELE CONVERSION
-
2.0x (EX S), 1.4x (EX M) *Only for still image recording.
-
PHOTO STYLE
-
Photo Style
-
Standard / Vivid / Natural / L. Classic Neo (Firmware version 1.9)* / Flat / Landscape / Portrait / Monochrome / L. Monochrome / L. Monochrome D / L. Monochrome S (Firmware version 1.9)* / Cinelike D / Cinelike V / Like709 / Like2100 (HLG) (Firmware version 1.6 or later)* / Standard (HLG) / Monochrome (HLG) / My Photo Style 1-10 *Firmware must be updated.
-
-
Picture adjustment
-
Contrast / Highlight / Shadow / Saturation / Color Tone / Hue / Filter Effect / Grain Effect / Color Noise* / Sharpness / Noise Reduction / ISO / WB (Adjustable settings vary depending on the Photo Style mode.) *Firmware must be updated to version 1.9.
-
FILTER
-
FILTER
-
Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine*
*For photos only.
-
MOTION PICTURE FUNCTION
-
Vertical Position Information*
-
ON / Off *Firmware must be updated to version 1.8 or later.
-
-
SS/Gain operation(*8)
-
Shutter Duration/ISO / Angle/ISO / Shutter Duration/dB
-
-
SS/Gain operation (*9)
-
Shutter Duration/ISO / Angle/ISO / Shutter Duration/dB
-
FUNCTION BUTTON
-
REC
-
Exposure Comp. / Sensitivity / White Balance / Photo Style / Metering Mode / Aspect Ratio / Picture Quality / Picture Size / HLG Photo / High Resolution Mode / 1 Shot Spot Metering / Long Exposure NR / Min. Shutter Speed / 1 Shot RAW+JPG / i.Dynamic Range / Filter Effect / One Push AE / Touch AE / Exposure Mode / AF Mode/MF / AF Custom Setting(Photo) / AF Custom Setting(Video) / Focus Peaking / Focus Peaking Sensitivity / 1-Area AF Moving Speed / Focus Ring Lock / AE LOCK / AF LOCK / AF/AE LOCK / AF-ON / AF-ON: Near Shift***** / AF-ON: Far Shift***** / AF-Point Scope / Focus Area Set / Flash Mode / Flash Adjust. / Wireless Flash Setup / Drive Mode / 1 Shot "6K/4K PHOTO" / Bracketing / Silent Mode / Image Stabilizer / Shutter Type / Ex. Tele Conv. / Flicker Decrease (Photo) / Post-Focus / Motion Pic. Rec Format / Motion Pic. Rec Quality / Sound Rec Level Disp. / Sound Rec Level Adj. / Mic. Directivity Adjust / Image Stabilizer / E-Stabilization (Video) / Boost I.S. (Video) / Q.MENU / Rec / Playback Switch / Video Record / LVF/Monitor Switch / LVF Magnification / Dial Operation Switch / Preview / Preview Aperture Effect****** / Constant Preview / Level Gauge / Histogram / Photo Grid Line / Live View Boost / Monochrome Live View / Night Mode / LVF/Monitor Disp. Style / Photo/Video Preview / Zebra Pattern / HLG View Assist(Monitor) / HLG View Assist (HDMI) / Sheer Overlay / I.S. Status Scope / Focus Ring Control/ Zoom Control / Destination Card Slot / Wi-Fi / No Setting / Off (Disable Press and Hold)****** / Restore to Default
-
-
PLAY
-
Magnify from AF Point / HLG View Assist(Monitor) / RAW Processing / 6K/4K PHOTO Bulk Saving / Delete Single / Protect / Rating 1, 2, 3, 4, 5 / Copy / Rec/Playback Switch / LVF/Monitor Switch / Video Record / Night Mode / Card Slot Change / Wi-Fi / Send Image (Smartphone) / HLG View Assist (HDMI) / 6K/4K Photo Play / No Setting / Off (Disable Press and Hold)****** / Restore to Default
-
Fn LEVER
-
Fn LEVER
-
AF Mode / Photo Style / Picture Quality / Long Exposure NR / Focus Peaking / Bracketing / Silent Mode / Image Stabilizer / Shutter Type / 6K/4K PHOTO (Pre-Burst) / Focus Ring Lock / Touch Screen / Touch Pad AF / Auto Review (Photo) / Live View Boost / Night Mode / Sheer Overlay / Front/Rear/Control Dial Lock / No Setting / Restore to Default
-
LEVEL GAUGE
-
LEVEL GAUGE
-
Yes
-
OSD LANGUAGE
-
OSD LANGUAGE
-
Japanese, English, German, French, Italian, Spanish, Chinese (Traditional), Chinese (Simplified)
-
-
PRINT
-
PictBridge compatible
-
INTERFACE
-
USB
-
SuperSpeed USB 3.1 Gen1 Type-C
-
-
HDMI*** Monitor-through
-
4:2:2 8bit (Except for [4K/60p]/[4K/50p]*******) / 4:2:0 8bit
4:2:2 10bit******** (When [4K/60p]/[4K/50p] mode is selected in [Rec Quality], it is not possible to record motion picture or still picture on the memory card in the camera unit.)
-
-
HDMI*** Playback
-
HDMI TypeA / VIERA Link
Video: Auto / 4K/50p / 4K/25p / 1080p / 1080i / 720p / 576p
Audio: Stereo
-
-
Audio video output
-
No
-
-
Remote input
-
φ2.5mm
-
-
External microphone / external audio device input
-
φ3.5mm for external microphone / external audio device
MIC (Plug-in Power) / MIC / LINE is selectable.
Stereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching DMW-MS2 (sold separately).
-
-
Headphone output
-
φ3.5mm
-
-
Microphone
-
Stereo, Wind Noise Canceller: OFF / Low* / Standard / High *When attaching DMW-MS2 (sold separately).
-
-
Speaker
-
Monaural
-
-
Card slot
-
Slot 1: XQD Memory Card, CFexpress Card (CFexpress Ver2.0 Type B)******
Slot 2: SD Memory Card, SDHC Memory Card*, SDXC Memory Card*
*Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.
-
WIRELESS
-
Wi-Fi
-
2.4GHz bands (STA/AP) (IEEE802.11b/g/n)
5GHz bands (STA) (IEEE 802.11a/n/ac) *5GHz Wi-Fi is not available in some countries.
1-13, 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140, 149, 153, 157, 161, 165 ch
-
-
Bluetooth
-
Bluetooth® v4.2 (Bluetooth Low Energy (BLE))
-
DUST AND SPLASH RESISTANT
-
DUST AND SPLASH RESISTANT*
-
Yes.
*Dust and Splash Resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.
-
POWER
-
Battery
-
Li-ion Battery Pack (7.4V, 3050mAh, 23Wh) (bundled)
USB power supply, USB power charging
-
-
Battery life (CIPA standard)/ When using CFexpress Card
-
Approx. 360 images (rear monitor), 340 images (LVF), 1,100 images (Power Save LVF mode*) with S-R24105
*Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
-
-
Battery life (CIPA standard)/ When using XQD memory card
-
Approx. 360 images (rear monitor), 340 images (LVF), 1,100 images (Power Save LVF mode*) with S-R24105
*Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
-
-
Battery life (CIPA standard)/ When using SD memory card
-
Approx. 380 images (rear monitor), 360 images (LVF), 1,150 images (Power Save LVF mode*) with S-R24105
*Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
-
-
Battery grip
-
DMW-BGS1 (sold separately)
-
DIMENSIONS / WEIGHT
-
Dimensions (W x H x D)
-
Approx. 148.9 x 110.0 x 96.7 mm / 5.86 x 4.33 x 3.81 inch (excluding protrusions)
-
-
Weight
-
Approx. 1,020g / 2.25 lb (XQD Memory Card x 1, Battery, Body)
Approx. 1,016g / 2.24 lb (SD Memory Card x 1, Battery, Body)
Approx. 898g / 1.98 lb (Body only)
-
OPERATING ENVIRONMENT
-
Operating temperature****
-
-10oC to 40oC (14oF to 104oF)
-
-
Operating humidity
-
10%RH to 80％RH
-
STANDARD ACCESSORIES
-
Software- Recording
-
LUMIX Tether
・ This software is used to control a Panasonic digital camera from a PC. It allows you to change various settings of the camera, perform remote recording,
and save remotely recorded images to the PC. Check the site below to download and install the software.
http://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html (For Windows / Mac)
-
-
Software- Playback / Editing
-
・ The software to edit and playback images on computer is not bundled with this camera. To do this, PHOTOfunSTUDIO 10.1PE is available for download at Panasonic website using computer connected to the Internet.
https://panasonic.jp/support/global/cs/soft/download/d_pfs1001pe.html(For Windows)
・ The software to process RAW file on computer is not bundled with this camera. To do this, SILKYPIX Developer Studio is available for download at Ichikawa Soft Laboratory's website using computer connected to the Internet.
http://www.isl.co.jp/SILKYPIX/english/p/ (For Windows / Mac)
-
-
Standard accessories
-
DC-S1R Kit
Body Cap, Hot Shoe Cover, Eye Cup, Flash Synchro Socket Cap, Cover for the Battery Grip Connector, Shoulder Strap, Battery Pack, Battery Charger, AC Adaptor, AC Mains Lead,
USB Connection Cable (C-C), USB Connection Cable (A-C), Cable Holder
・ The DC-S1R Operating Instructions for advanced features is available for downloaded at Panasonic LUMIX Customer Support Site using PC, smartphone or tablet connected to the Internet.
-
NOTE
-
NOTE
-
** About motion picture recording / 6K PHOTO/4K PHOTO recording
- 6K PHOTO is a high speed burst shooting function that cuts a still image out of a 4:3 or 3:2 video footage with approx. 18-megapixel (approx. 6000 x 3000 effective pixel count) that the 6K image manages.
- Use an SD memory card with SD Speed Class with ""Class 4"" or higher when recording motion pictures in [AVCHD].
- Use an XQD or SD memory card with SD Speed Class with ""Class 4"" or higher when recording motion pictures in [MP4(under 28Mbps)].
- Use an XQD or SD memory card with SD Speed Class with ""UHS-I / UHS-II UHS Speed Class 3 (U3)"" when recording motion pictures with [MP4] in [4K] [High Speed Video] [6K PHOTO/4K PHOTO] or [MOV].
(SD speed class is the speed standard regarding continuous writing.)
- Recording stops when the continuous recording time exceeds 10 minutes with [MP4] in [High Speed Video] [6K PHOTO].
- Recording stops when the continuous recording time exceeds 15 minutes with [MP4] in [4K] [4K PHOTO] or [MOV].
- Motion pictures with [MP4] in [4K] or [MOV]:
- When using an XQD memory card of 32 GB or less, or an SDHC memory card: You can continue recording without interruption even if the file size exceeds 4 GB, but the motion picture file will be divided and recorded/played back separately.
- When using an XQD memory card over 32 GB, or an SDXC memory card: You can continue recording without interruption even if the file size exceeds 96 GB or 3 hours 4 minutes in length, but the motion picture file will be divided and recorded/played back separately.
- Motion pictures with [MP4] in [FHD]:
- You can continue recording without interruption even if the file size exceeds 4 GB or 30 minutes in length, but the motion picture file will be divided and recorded/played back separately.
- When the ambient temperature is high or continuous recording is performed, the camera may stop the recording to protect itself. Wait until the camera cools down.
- XQD is a registered trademark of Sony Corporation.
*** For [5K] [4K/60p] [4K/50p] video output, use an HDMI2.0 cable that has the HDMI logo on it, and that is described as""4K compatible"".
**** The camera may stop recording when used in lower or higher than recommended operating temperature: -10 to 40 degrees.
***** Firmware must be updated to version 1.2 or later.
****** Firmware must be updated to version 1.3 or later.
******* Firmware must be updated to version 1.6 or later.
-
Related Products
Reviews
Customer Reviews
-
EISA – Expert Imaging and Sound Association
The Panasonic LUMIX DC-S1R is an extremely well built professional camera with significant protection against the elements. It combines speedy performance with exceptional image quality that stands out from even the best of its competitors.
