Cinematic Performance, Boundless Creativity.

The LUMIX S1H full-frame mirrorless camera delivers stunning cinema-quality video. Featuring V-Log/V-Gamut with 14+ stops of dynamic range, 6K full-frame capture, 10-bit Cinema 4K/4K 60p/50p recording, and unlimited recording time.
Includes LUMIX S1H body only.

Download Latest Firmware here ■

Add to WishlistRemove from Wishlist

DC-S1HGN-K

Price (RRP)5,999.00

Buy

Features

Newly Designed Full-frame Sensor with Dual Native ISO Technology

The newly designed 24.2-megapixel full-frame CMOS sensor of the LUMIX S1H features Dual Native ISO technology. The image sensor can leverage a dual-base ISO setting, resulting in minimized noise and outstanding image quality from low to high sensitivity. This feature teams up with the Venus Engine to deliver maximum ISO 51200 / Extended ISO 204800 for minimal noise at high sensitivity and beautiful expression of dark areas in the frame. In addition, a low-pass filter effectively minimizes moiré patterns. Whenever professional-level low-light shooting is required, the LUMIX S1H is ready for action.

Wide Range of Recording Formats

With its full range of recording modes, the LUMIX S1H has every industry covered, from cinema to TV broadcasting. In addition to C4K/4K 60p/50p* 4:2:0 10-bit and C4K/4K 30p/25p/24p 4:2:2 10-bit, the camera newly offers 6K/24p 4:2:0 10-bit in 3:2 and 5.9K 30p/25p/24p 4:2:0 10-bit in 16:9. Anamorphic mode in 4K is also available. Ultra-high image quality, flexibility, and expressiveness — the LUMIX S1H is ready for today’s demanding shoots.

* In Super 35mm and PIXEL/PIXEL settings.

Learn About S1H Video Shooting Performance

4:2:2 10-bit Internal Recording / HDMI Output

Featuring an incredibly rich colour profile, C4K/4K 30p/25p/24p 4:2:2 10-bit video is recordable in-camera. In the 10-bit setting, 4:2:2 10-bit HDMI output is supported along with simultaneous external drive / SD card recording.

Leveraging the expressive power of a full-frame camera takes 4K video to exciting new places. Also, 5.9K/4K/Anamorphic 3.5K(4:3) 12-bit RAW output has become possible with a firmware update.*

* Firmware must be updated to version 2.1 or later. Use the ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.52 or higher). This does not guarantee all of the capabilities that the compatible external recorder may have.
・ HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

4:2:2 10-bit Internal Recording / HDMI Output

RAW Video Data Output for Professional Film Creation

Trademarks and Licenses

･ All functions may not be available depending on the situation.
･ Software that supports Apple ProRes RAW is required to edit RAW video recorded with NINJA V.
･ Selectable recording mode depends on the firmware version of Video Assist 12G HDR.
･ DaVinci Resolve or DaVinci Resolve Studio is required to play back the Blackmagic RAW data. DaVinci Resolve Studio is required to edit the Blackmagic RAW data.
･ Apple and ProRes are trademarks or registered trademarks of Apple Inc. in the United States and/or other countries.
･ Ninja V / ATOMOS are registered trademarks of ATOMOS Limited.
･ ‘Blackmagic Design’, ‘Blackmagic RAW’ and ‘DaVinci Resolve’ are registered trademarks of Blackmagic Design Pty. Ltd.

RAW Video Data Output for Professional Film Creation

The firmware update enables the output of maximum 29.97p 5.9K (5888x3312, 16:9) / 59.94p 4K (4128x2176, 17:9) and Anamorphic 3.5K (3536x2656, 4:3) 12-bit RAW video data over HDMI to save it as Apple ProRes RAW on the AtomosNinja V 4K HDR monitor-recorder.* The BlackmagicRAW can also be recorded on Video Assist 12G HDR.**

* Please update the firmware to version 2.1 or later.
** Please update the firmware to version 2.4 or later.

RAW Video Data Output for Professional Film Creation

Trademarks and Licenses

RAW Video Data Output for Professional Film Creation

* Please update the firmware to version 2.1 or later.
** Please update the firmware to version 2.4 or later.

RAW Video Data Output for Professional Film Creation

Trademarks and Licenses

V-Log/V-Gamut with 14+ Stops of Dynamic Range

Offering compatibility with Cinema VariCam Look, 14+ stops of dynamic range, and a very wide colour spectrum, V-Log and V-Gamut come preinstalled. Users will enjoy impressively accurate colour reproduction, subtle gradations from dark areas to highlights, and precise control of colour data in post-production. The end result is more creative and satisfying colour expression. Moreover, footage shot with the LUMIX S1H can be seamlessly edited with footage shot with VariCam cameras. As a further convenient touch, the LUT in use is displayed on the camera monitor. The V-Log of the LUMIX S1H offers 14+ stops of dynamic range, which covers the PQ requirement of HDR, while V-Gamut covers the full HDR colour spectrum, giving users access to HDR shooting wherever, whenever.

Robust Video Expression Features (HDR, VFR, HFR)

From basic functionality to advanced technology, the LUMIX S1H is designed to offer outstanding, multifaceted video performance. VFR (variable frame rate) functionality supports both overcranking and undercranking. Users have access to 2.5x slow (24p/60 fps) in C4K/4K and 7.5x super-slow (24p/180 fps) in FHD.* HFR (high frame rate) recording includes audio and autofocus, allowing users to create slow-motion video in post-production. Hybrid Log Gamma (HLG) is a high dynamic range (HDR) format that further expands users’ ability to create amazing video.

* The degree of effect varies depending on the recording format and frequency, and the angle of view narrows if a frame rate over 150 fps is selected.

Robust Video Expression Features (HDR, VFR, HFR)

First Fan Ever in a Full-frame DSLM Camera* Supports Unlimited Video Recording

For the first time ever in a full-frame digital single-lens mirrorless camera,* the LUMIX S1H incorporates a fan as standard equipment — a feature typically found only on professional cameras. The fan is part of a newly developed heat-dispersing structure that supports unlimited video recording. The dust- and splash-resistant design,** low vibrations for minimal effect on the image stabilisation system, and ultra-quiet performance are other features that complement this new structure.
The fan can be used with four different settings. For example, AUTO1 starts the fan soon after shooting begins to keep heat down and facilitate longer shoots. AUTO2 prioritizes quiet performance and keeps the fan off as much as possible.

* Among full-frame digital single-lens mirrorless cameras as of August 27, 2019. ** Dust- and splash-resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.

First Fan Ever in a Full-frame DSLM Camera* Supports Unlimited Video Recording

Newly Developed Tilt and Free-Angle Rear Monitor

The newly developed tilt and free-angle rear monitor leverages the convenience of both a tilt monitor and a free-angle monitor. Even with an HDMI or USB cable attached to the camera, the monitor can move freely. As a result, it is possible to use an HDMI monitor or external recorder while freely checking the camera monitor.

The large 3.2-inch, 2.33-million-dot monitor is 1.5x brighter than the brightest LUMIX monitor to date,* allowing users to enjoy outstanding visibility even in bright sunlight. Moreover, the large status LCD presents optimized information about both still photographs and videos, providing easy access to time codes, the audio level meter, and more.

* Comparison with LUMIX S1R, S1, GH5 and GH5S.

Tough Body for a Wide Range of Weather Conditions

The tough body is ready to take on a variety of challenging shooting environments. The magnesium alloy full die-cast frame is highly durable, while sealing helps protect every seam, dial, and button. The camera as a whole is dust- and splash-resistant* and designed for use at temperatures as low as -10 °C. In combination, these features help make shooting both productive and enjoyable in a wide range of weather conditions.

* Dust- and splash-resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.

Tough Body for a Wide Range of Weather Conditions

Learn More about S1H Camera Features

Responding to the demanding requirements of videographers today, the LUMIX S1H full-frame mirrorless camera offers an outstanding combination of image quality, functionality, and usability.

Learn more about the LUMIX S1H video & photo shooting performance, body design & expandability, as well as its durability and reliability via the button below.

Learn More

Get Inspired

Specs

Photo of LUMIX S1H Full-Frame Mirrorless Camera – Body Only

Size and Weight

Height: 114.2mm

Width: 151.0mm

Depth: 110.4mm

Weight: 1164g

All values are approximate. Weight with SD card and battery. Lens is excluded. Dimensions exclude protrusions.

L-Mount
24.2 Megapixels
4K Video Recording Capability
6K 24P Video Recording Capability
14+ stops V-Log
5-Axis Dual I.S. 2 (Image Stabilizer)
5760k-dot OLED Live View Finder
2330k-dot Tilt Free-angle Monitor
Status LCD
Splash, Dust and Freeze-resistant
Wi-Fi
Bluetooth

24.2MP full-frame CMOS sensor with Dual Native ISO technology

C4K/4K 60p/50p 10-bit video, 6K/24p 3:2 10-bit video and unlimited recording time

10-bit internal / external simultaneous recording

14+ stops of V-Log/V-Gamut

TYPE

Type
- Digital Single Lens Mirrorless camera
Recording media
- SD Memory Card / SDHC Memory Card* / SDXC Memory Card*
  *Compatible with UHS-I/UHS-II UHS Speed Class 3 standard SDHC/SDXC Memory Cards and UHS-II Video Speed Class 90 standard SDXC Memory Cards.
Lens mount
- L-Mount

IMAGE SENSOR

Type
- 35mm full-frame (35.6mm x 23.8mm) CMOS sensor
Camera effective pixels / Total pixels
- 24.20 megapixels / 25.28 megapixels
Aspect ratio / Colour filter
- 3:2 / Primary colour filter
Dust reduction system
- Supersonic wave filter

LATITUDE

LATITUDE
- 14+ stops (V-Log)

STILL IMAGE

Recording file format
- Still image
  - JPEG (DCF, Exif 2.31), RAW, HLG Photo (CTA-2072)
- 6K PHOTO*** / 4K PHOTO***
  - 6K PHOTO: MP4 (H.265/HEVC, Audio format: AAC (2ch))
    4K PHOTO: MP4 (H.264/MPEG-4 AVC, Audio format: AAC (2ch))
    Extracted still images: JPEG (DCF, Exif 2.31)
Aspect ratio
- Aspect ratio
  - 4:3 / 3:2 / 16:9 / 1:1 / 65:24 / 2:1
File size (Pixels)
- When using full-frame lenses, 3:2
  - 6000x4000(L) / 4272x2848(M) / 3024x2016(S) / 12000x8000(XL)* *High Resolution Mode. RAW file.
    5184x3456(6K PHOTO) / 3504x2336(4K PHOTO) / 5984x4000(HLG PHOTO, Full-Res.) / 3232x2160(HLG PHOTO, 4K-Res.)
- When using full-frame lenses, 4:3
  - 5328x4000(L) / 3792x2848(M) / 2688x2016(S) / 10656x8000(XL)* *High Resolution Mode. RAW file.
    4992x3744(6K PHOTO) / 3328x2496(4K PHOTO) / 5312x3984(HLG PHOTO, Full-Res.) / 2880x2160(HLG PHOTO, 4K-Res.)
- When using full-frame lenses, 16:9
  - 6000x3368(L) / 4272x2400(M) / 3024x1704(S) / 12000x6736(XL)* *High Resolution Mode. RAW file.
    3840x2160(4K PHOTO) / 5888x3312(HLG PHOTO, Full-Res.) / 3840x2160(HLG PHOTO, 4K-Res.)
- When using full-frame lenses, 1:1
  - 4000x4000(L) / 2848x2848(M) / 2016x2016(S) / 8000x8000(XL)* *High Resolution Mode. RAW file.
    2880x2880(4K PHOTO) / 4000x4000(HLG PHOTO, Full-Res.) / 2144x2144(HLG PHOTO, 4K-Res.)
- When using full-frame lenses, 65:24
  - 6000x2208(L)
- When using full-frame lenses, 2:1
  - 6000x3000(L)
- When using Super 35mm (APS-C) lenses, 3:2
  - 3888x2592(L) / 2784x1856(M) / 1968x1312(S) / 3504x2336(4K PHOTO)
- When using Super 35mm (APS-C) lenses, 4:3
  - 3536x2656(L) / 2560x1920(M) / 1840x1376(S) / 3328x2496(4K PHOTO)
- When using Super 35mm (APS-C) lenses, 16:9
  - 4064x2288(L) / 2816x1584(M) / 1920x1080(S) / 3840x2160(4K PHOTO)
- When using Super 35mm (APS-C) lenses, 1:1
  - 2656x2656(L) / 1920x1920(M) / 1376x1376(S) / 2880x2880(4K PHOTO)
Image quality
- RAW / RAW+Fine / RAW+Standard / Fine / Standard
Colour space
- sRGB, AdobeRGB

MOTION PICTURE

Recording file format
- MOV: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: LPCM (2ch 48kHz/16-bit, 48kHz/24-bit*, 96kHz/24-bit*)) *When attaching DMW-XLR1 (sold separately).
  MP4: H.264/MPEG-4 AVC, H.265/HEVC (Audio format: AAC (2ch))
  AVCHD Progressive, AVCHD (Audio format: Dolby Audio (2ch))
System frequency
- 59.94Hz / 50.00Hz / 24.00Hz
MOV*** High-res audio is selectable only when using the DMW-XLR1 (sold separately).
- 59.94Hz Full-frame
  - [6K] 5952x3968 (3:2) 23.98p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [5.4K] 5376x3584 (3:2) 29.97p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [5.9K] 5888x3312 29.97p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [5.9K] 5888x3312 23.98p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 29.97p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 23.98p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 29.97p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 23.98p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 119.88p, 150Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 59.94p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 59.94i, 100Mbps (4:2:2 10-bit ALL-Intra)* / 50Mbps (4:2:2 10-bit LongGOP)* (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 47.95p, 100Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 29.97p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 23.98p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
- 59.94Hz Super 35mm / Pixel by Pixel
  - [C4K] 4096x2160 59.94p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 59.94p, 150Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio)
    [C4K] 4096x2160 47.95p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 29.97p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 23.98p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 59.94p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 59.94p, 150Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio)
    [4K] 3840x2160 47.95p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 29.97p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 23.98p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [Anamorphic 4K] 3328x2496 (4:3) 47.95p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [Anamorphic 4K] 3328x2496 (4:3) 29.97p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [Anamorphic 4K] 3328x2496 (4:3) 23.98p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 119.88p, 150Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *When Super 35mm is selected. HLG is selectable.
    [FHD] 1920x1080 59.94p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 59.94i, 100Mbps (4:2:2 10-bit ALL-Intra)* / 50Mbps (4:2:2 10-bit LongGOP)* (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 47.95p, 100Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 29.97p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 23.98p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
- 50.00Hz Full-frame
  - [5.4K] 5376x3584 (3:2) 25.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [5.9K] 5888x3312 25.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 25.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 25.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 100.00p, 150Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 50.00p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 50.00i, 100Mbps (4:2:2 10-bit ALL-Intra)* / 50Mbps (4:2:2 10-bit LongGOP), (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 25.00p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
- 50.00Hz Super 35mm / Pixel by Pixel
  - [C4K] 4096x2160 50.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 50.00p, 150Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio)
    [C4K] 4096x2160 25.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 50.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 50.00p, 150Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio)
    [4K] 3840x2160 25.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [Anamorphic 4K] 3328x2496 (4:3) 50.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [Anamorphic 4K] 3328x2496 (4:3) 50.00p, 150Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio)
    [Anamorphic 4K] 3328x2496 (4:3) 25.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 100.00p, 150Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *When Super 35mm is selected. HLG is selectable.
    [FHD] 1920x1080 50.00p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 50.00i, 100Mbps (4:2:2 10-bit ALL-Intra)* / 50Mbps (4:2:2 10-bit LongGOP)* (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 25.00p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
- 24.00Hz Full-frame
  - [6K] 5952x3968 (3:2) 24.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [5.9K] 5888x3312 24.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 24.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 24.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 48.00p, 100Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 24.00p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
- 24.00Hz Super 35mm / Pixel by Pixel
  - [C4K] 4096x2160 48.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [C4K] 4096x2160 24.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 48.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [4K] 3840x2160 24.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [Anamorphic 4K] 3328x2496 (4:3) 48.00p, 200Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable
    [Anamorphic 4K] 3328x2496 (4:3) 24.00p, 400Mbps (4:2:2 10-bit ALL-Intra)* / 150Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 48.00p, 100Mbps (4:2:0 10-bit LongGOP)* (H.265/HEVC, LPCM, High-Res Audio) *HLG is selectable.
    [FHD] 1920x1080 24.00p, 200Mbps (4:2:2 10-bit ALL-Intra)* / 100Mbps (4:2:2 10-bit LongGOP)* / 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM, High-Res Audio) *HLG is selectable.
MP4***
- 59.94Hz Full-frame
  - [4K] 3840x2160 29.97p, 72Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 23.98p, 72Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 29.97p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [4K] 3840x2160 23.98p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 59.94p, 28Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 29.97p, 20Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 23.98p, 24Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
- 59.94Hz Super 35mm / Pixel by Pixel
  - [4K] 3840x2160 59.94p, 100Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 29.97p, 72Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 23.98p, 72Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 29.97p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [4K] 3840x2160 23.98p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 59.94p, 28Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 29.97p, 20Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 23.98p, 24Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
- 50.00Hz Full-frame
  - [4K] 3840x2160 25.00p, 72Mbps (4:2:0 10-bit LongGOP)(H.265/HEVC, AAC)
    [4K] 3840x2160 25.00p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 50.00p, 28Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 25.00p, 20Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
- 50.00Hz Super 35mm / Pixel by Pixel
  - [4K] 3840x2160 50.00p, 100Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 25.00p, 72Mbps (4:2:0 10-bit LongGOP) (H.265/HEVC, AAC)
    [4K] 3840x2160 25.00p, 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 50.00p, 28Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
    [FHD] 1920x1080 25.00p, 20Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, AAC)
- 24.00Hz Full-frame / Super 35mm / Pixel by Pixel
  - -
AVCHD Progressive*** / AVCHD***
- 59.94Hz Full-frame / Super 35mm / Pixel by Pixel
  - [FHD] 1920x1080 59.94p (Sensor output is 59.94fps), 28Mbps (4:2:0 8-bit LongGOP) (Dolby)
    [FHD] 1920x1080 59.94i (Sensor output is 59.94fps), 17Mbps (4:2:0 8-bit LongGOP) (Dolby)
    [FHD] 1920x1080 59.94i (Sensor output is 29.97fps), 24Mbps (4:2:0 8-bit LongGOP) (Dolby)
    [FHD] 1920x1080 23.98p (Sensor output is 23.98fps), 24Mbps (4:2:0 8-bit LongGOP) (Dolby)
- 50.00Hz Full-frame / Super 35mm / Pixel by Pixel
  - [FHD] 1920x1080 50.00p (Sensor output is 50.00fps), 28Mbps (4:2:0 8-bit LongGOP) (Dolby)
    [FHD] 1920x1080 50.00i (Sensor output is 50.00fps), 17Mbps (4:2:0 8-bit LongGOP) (Dolby)
    [FHD] 1920x1080 50.00i (Sensor output is 25.00fps), 24Mbps (4:2:0 8-bit LongGOP) (Dolby)
- 24.00Hz Full-frame / Super 35mm / Pixel by Pixel
  - -
Continuous recordable time
- Continuous recordable time (Motion picture)***
  - AVCHD [FHD/60p]: Approx. 160 min (Full-frame), 140 min (Super 35mm), 150 min (Pixel by Pixel) *When using S-R24105. When the battery is fully charged.
    MP4 [4K/60p]: Approx. 120 min (Super 35mm, Pixel by Pixel) *When using S-R24105. When the battery is fully charged.
    MOV [C4K/24p/4:2:2 10-bit/ALL-Intra]: Approx. 130 min (Full-frame, Super 35mm, Pixel by Pixel) *When using S-R24105. When the battery is fully charged.
Actual recordable time
- Actual recordable time (Motion picture)***
  - AVCHD [FHD/60p]: Approx. 80 min (Full-frame), 70 min (Super 35mm), 75 min (Pixel by Pixel) *When using S-R24105. When the battery is fully charged.
    MP4 [4K/60p]: Approx. 60 min (Super 35mm, Pixel by Pixel) *When using S-R24105. When the battery is fully charged.
    MOV [C4K/24p/4:2:2 10-bit/ALL-Intra]: Approx. 65 min (Full-frame, Super 35mm, Pixel by Pixel) *When using S-R24105. When the battery is fully charged.

VARIABLE FRAME RATE

MOV***
- 59.94Hz Full-frame
  - [FHD] 1920x1080 59.94p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    [FHD] 1920x1080 29.97p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    [FHD] 1920x1080 23.98p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 59.94Hz Super 35mm
  - [C4K] 4096x2160 29.97p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [C4K] 4096x2160 23.98p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [4K] 3840x2160 29.97p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (LPCM)
    [4K] 3840x2160 23.98p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 29.97p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 23.98p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x1080 59.94p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    [FHD] 1920x1080 29.97p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    [FHD] 23.98p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 59.94Hz Pixel by Pixel
  - [C4K] 4096x2160 29.97p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [C4K] 4096x2160 23.98p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [4K] 3840x2160 29.97p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [4K] 3840x2160 23.98p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 29.97p (Maximum output of sensor is 50fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 23.98p (Maximum output of sensor is 48fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x1080 29.97p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x1080 23.98p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
- 50.00Hz Full-frame
  - [FHD] 1920x1080 50.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    [FHD] 1920x1080 25.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 50.00Hz Super 35mm
  - [C4K] 4096x2160 25.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [4K] 3840x2160 25.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 25.00p (Maximum output of sensor is 50fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x108050.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    [FHD] 1920x1080 25.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 50.00Hz Pixel by Pixel
  - [C4K] 4096x2160 25.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [4K] 3840x2160 25.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 25.00p (Maximum output of sensor is 50fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x1080 24.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 24.00Hz Full-frame
  - [FHD] 1920x1080 24.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 24.00Hz Super 35mm
  - [C4K] 4096x2160 24.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [4K] 3840x2160 24.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3)24.00p (Maximum output of sensor is 48fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x1080 24.00p (Maximum output of sensor is 180fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)*
    *Angle of view narrows if you select a frame rate with a number of frames 151 or more.
- 24.00Hz Pixel by Pixel
  - [C4K] 4096x2160 24.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)　
    [4K] 3840x2160 24.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [Anamorphic 4K] 3328x2496 (4:3) 24.00p (Maximum output of sensor is 48fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
    [FHD] 1920x1080 24.00p (Maximum output of sensor is 60fps), 100Mbps (4:2:0 8-bit LongGOP) (H.264/MPEG-4 AVC, LPCM)
AVCHD Progressive*** / AVCHD***
- 59.94Hz Full-frame / Super 35mm / Pixel by Pixel
  - [FHD] 1920x1080 59.94i (Maximum output of sensor is 60fps), 24Mbps (4:2:0 8-bit LongGOP) (Dolby)
    [FHD] 1920x1080 23.98p (Maximum output of sensor is 60fps), 24Mbps (4:2:0 8-bit LongGOP) (Dolby)
- 50.00Hz Full-frame / Super 35mm / Pixel by Pixel
  - [FHD] 1920x1080 50.00i (Maximum output of sensor is 60fps), 24Mbps (4:2:0 8-bit LongGOP) (Dolby)

HDMI RAW DATA OUTPUT****** Use the ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.52 or higher). This does not guarantee all of the capabilities that the compatible external recorder may have.

Rec quality
- NTSC (59.94Hz) Full-frame
  - [5.9K] 5888x3312 29.97p, 12-bit (LPCM, High-Res Audio)
    [5.9K] 5888x3312 23.98p, 12-bit (LPCM, High-Res Audio)
- NTSC (59.94Hz) Super 35mm
  - [4K] 4128x2176 (17:9) 59.94p, 12-bit (LPCM, High-Res Audio)
    [4K] 4128x2176 (17:9) 29.97p, 12-bit (LPCM, High-Res Audio)
    [4K] 4128x2176 (17:9) 23.98p, 12-bit (LPCM, High-Res Audio)
    [Anamorphic 3.5K] 3536x2656 (4:3) 29.97p, 12-bit (LPCM, High-Res Audio)
    [Anamorphic 3.5K] 3536x2656 (4:3) 23.98p, 12-bit (LPCM, High-Res Audio)
- PAL (50.00Hz) Full-frame
  - [5.9K] 5888x3312 25.00p, 12-bit (LPCM, High-Res Audio)
- PAL (50.00Hz) Super 35mm
  - [4K] 4128x2176 (17:9) 50.00p, 12-bit (LPCM, High-Res Audio)
    [4K] 4128x2176 (17:9) 25.00p, 12-bit (LPCM, High-Res Audio)
    [Anamorphic 3.5K] 3536x2656 (4:3) 50.00p, 12-bit (LPCM, High-Res Audio)
    [Anamorphic 3.5K] 3536x2656 (4:3) 25.00p, 12-bit (LPCM, High-Res Audio)
Audio format
- LPCM (2ch 48kHz/16-bit, 48kHz/24-bit*, 96kHz/24-bit*) *High-res audio is selectable only when using the DMW-XLR1 (sold separately).

VIEWFINDER

Type
- OLED Live View Finder
Pixels
- Approx. 5.76 million dots
Field of view / Magnification
- Approx. 100% / Approx. 0.78x with 50 mm lens at infinity; -1.0 m-1, when the aspect ratio is set to 3:2
Eye point / Diopter adjustment
- Approx. 21 mm at infinity; -1.0 m-1 / -4.0 - +2.0 (dpt)
Eye sensor
- Yes
Display speed
- 120fps / 60fps
Display time lag
- Approx. 0.005sec

REAR MONITOR

Type
- TFT LCD monitor with static touch control
Monitor size
- Tilt free-angle, 3.2-inch (8.0cm), 3:2 aspect
Pixels
- Approx. 2.33 million dots
Field of view
- Approx. 100%

STATUS LCD

STATUS LCD
- 1.8-inch, 303 x 230 dots (effective pixels 287 x 214 dots), Monochrome LCD monitor

FOCUS

Type
- Contrast AF system
DFD technology
- Yes
Focus mode
- AFS (Single) / AFC (Continuous) / MF
AF mode
- Auto Detection (Face, Eye, Body, Animal) / Tracking / 225-Area / Zone (Vertical/Horizontal) / Zone (Square) / Zone (Oval) / 1-Area+* / 1-Area* / Pinpoint / Custom 1, 2, 3
  (Full area touch is available) (Scalable AF frame size and flexible AF position) *Human/Animal Detection AF can be set ON or OFF.*******
AF detective range
- EV -6 - 20 (F1.4, ISO100 equivalent, AFS)
AF custom setting
- AF Sensitivity, AF Area Switching Sensitivity, Moving Object Prediction
AF assist lamp
- Yes
AF lock
- Set the Fn button in custom menu to AF lock
Post Focus / Focus Stacking
- Yes / Yes
Others
- AF-ON, Shutter AF, Half Press Release, Focus/Shutter Priority, Quick AF, Continuous AF (during motion picture recording), Eye Sensor AF, AF-Point Scope Setting, AF+MF, MF Guide, MF Assist, Touch MF Assist, Focus Peaking, Touch AF/AE Function, Touch Pad AF, Touch Shutter, Focus Switching for Vert/Hor, Focus Ring Lock, Show/Hide AF Mode, 1-Area AF Moving Speed, Loop Movement Focus Frame, AFC Start Point (225-Area), Lens Focus Resume, Focus Ring Control

EXPOSURE CONTROL

Light metering system
- 1,728-zone multi-pattern sensing system
Light metering mode
- Multiple / Centre Weighted / Spot / Highlight Weighted
Metering range
- EV0-18 (F2.0 lens, ISO100 equivalent)
Exposure mode
- Program AE / Aperture Priority AE / Shutter Priority AE / Manual Exposure
ISO sensitivity (Standard output sensitivity)
- Auto / 50* / 100 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 / 51200 / 102400* / 204800* (Changeable to 1/3 EV step) *Extended ISO
Dual Native ISO
- [Normal]
  Native ISO: 100, 640
  Auto: Auto / 50* / 100-51200 / 102400* / 204800* *Extended ISO
  Low: Auto / 50* / 100-800 *Extended ISO
  High: Auto / 320* / 640-51200 / 102400* / 204800* *Extended ISO

  [V-Log]
  Native ISO: 640, 4000
  Auto: Auto / 320* / 640-51200 *Extended ISO
  Low: Auto / 320* / 640-5000 *Extended ISO
  High: Auto / 2000* / 4000-51200 *Extended ISO

  [HLG]
  Native ISO: 400, 2500
  Auto: Auto / 400-51200 / 102400* / 204800* *Extended ISO
  Low: Auto / 400-3200
  High: Auto / 2500-51200 / 102400* / 204800* *Extended ISO

  [Cinelike D2 / Cinelike V2]
  Native ISO: 200, 1250
  Auto: Auto / 100* / 200-51200 / 102400* / 204800* *Extended ISO
  Low: Auto /100* / 200-1600 *Extended ISO
  High: Auto / 640* / 1250-51200 / 102400* / 204800* *Extended ISO
Exposure compensation
- 1/3 EV step ±5EV (±3EV for motion picture)
AE lock
- Set the Fn button in custom menu to AE lock

IMAGE STABILISATION SYSTEM

IMAGE STABILISATION SYSTEM
- Image sensor shift type (5-axis / 6.0-stop*) *Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=50mm when S-X50 is used.]
  Dual I.S. (6.5-stop* Dual I.S. 2 compatible) *Based on the CIPA standard [Yaw/Pitch direction: focusing distance f=105mm when S-R24105** is used. focusing distance f=200mm when S-R70200** is used.] **Firmware must be updated to the latest version.

WHITE BALANCE

White balance
- AWB / AWBc / AWBw / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2, 3, 4 / Colour temperature setting 1, 2, 3, 4
White balance adjustment
- Blue/Amber bias, Magenta/Green bias
Colour temperature setting
- 2500-10000K in 100K

SHUTTER

Type
- Focal-plane shutter
Shutter speed
- Still image: Bulb (Max. 30 minutes), 1/8,000 - 60
  Electronic front curtain shutter: Bulb (Max. 30 minutes), 1/2,000 - 60
  Electronic shutter: Bulb (Max. 60 sec), 1/8,000 - 60
  Motion picture: 1/16,000 - 1/25 (When using Synchro Scan)
  Creative Video M mode / MF mode: 1/16,000 - 1/2
Shutter life
- Approx. 400,000 images
Self timer
- 10sec, 3 images / 2sec / 10sec
Remote control
- Remote control by DMW-RS2 (sold separately)
Silent mode / Shutter type
- Yes / Yes (Auto / Mechanical / Electronic front curtain / Electronic / Electronic+NR)

BRACKET

AE bracket
- 3, 5, 7 images in 1/3, 2/3 or 1 EV step, max. ±3 EV, single/burst
Aperture bracket
- 3, 5 or all positions in 1 EV step
Focus bracket
- 1 to 999 images, focus steps can be set in 10 levels
White balance bracket
- 3 images in blue/amber axis or in magenta/green axis,colour temperature setting

BURST SHOOTING

Burst speed
- Mechanical shutter / Electronic front curtain shutter
  - AFS/MF: H: 9 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)
    AFC: H: 6 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)
- Electronic shutter
  - AFS/MF: H: 9 frames/sec, M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)
    AFC: H: 5 frames/sec (with Live View), M: 5 frames/sec (with Live View), L: 2 frames/sec (with Live View)
Number of recordable images
- RAW / RAW+JPEG: More than 60 images
  JPEG: More than 999 images (When using a card with SD Speed Class with "UHS-II UHS Speed Class 3 (U3)".)
  * Until the burst shooting speed slows. When recording is performed under the test conditions specified by Panasonic.

6K PHOTO* / 4K PHOTO*

Burst speed
- 6K PHOTO: 30 frames/sec
  4K PHOTO: 60 frames/sec, 30 frames/sec
Exif information
- Yes (Each JPEG image cropped out of the 6K/4K burst file complies with EXIF.)

FLASH

Flash type
- TTL External Flash (sold separately)
Flash mode
- Auto* / Auto/Red-eye Reduction* / Forced On / Forced On/Red-eye Reduction / Slow Sync. / Slow Sync./Red-eye Reduction / Forced Off *For iA only.
Flash synchronization
- 1st Curtain Sync, 2nd Curtain Sync.
Flash output adjustment
- 1/3EV step ±3EV
Synchronization speed
- Less than 1/320 second *The guide number decreases at 1/320 second. Only when set to M mode or S mode.
Wireless control
- Yes (When using DMW-FL200L / FL360L / FL580L (sold separately)), Wireless Channel: 1ch/2ch/3ch/4ch
Flash sync socket
- Yes

EXTRA TELE CONVERSION

EXTRA TELE CONVERSION
- 2.0x (EX S) (When using full-frame lenses), 1.9x (EX S) (When using Super 35mm (APS-C) lenses), 1.4x (EX M) *Only for still image recording.

PHOTO STYLE

Photo Style
- Standard / Vivid / Natural / Flat / Landscape / Portrait / Monochrome / L. Monochrome / L. Monochrome D / Cinelike D2 / Cinelike V2 / Like709 / V-Log / Standard (HLG) / Monochrome (HLG) / Like2100 / My Photo Style 1-10
Picture adjustment
- Contrast / Highlight / Shadow / Saturation / Colour Tone / Hue / Filter Effect / Grain Effect / Sharpness / Noise Reduction / Dual Native ISO Setting / ISO / WB
  *Adjustable settings vary depending on the Photo Style mode.

FILTER

FILTER
- Expressive / Retro / Old Days / High Key / Low Key / Sepia / Monochrome / Dynamic Monochrome / Rough Monochrome* / Silky Monochrome* / Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass / Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Colour / Sunshine*
  *For photos only.

MOTION PICTURE FUNCTION

Vertical Position Information ******
- ON / OFF

FUNCTION BUTTON

REC
- Exposure Comp. / Dual Native ISO Setting / Sensitivity / White Balance / Photo Style / Metering Mode / Aspect Ratio / Picture Quality / Picture Size / HLG Photo / High Resolution Mode / 1 Shot Spot Metering / Long Exposure NR / Min. Shutter Speed / 1 Shot RAW+JPG / i.Dynamic Range / Filter Effect / One Push AE / Touch AE / Exposure Mode / Synchro Scan / AF Mode / AF Custom Setting(Photo) / AF Custom Setting(Video) / Focus Peaking / Focus Peaking Sensitivity / 1-Area AF Moving Speed / Focus Ring Lock / AE LOCK / AF LOCK / AF/AE LOCK / AF-ON / AF-ON: Near Shift / AF-ON: Far Shift / AF-Point Scope / Focus Area Set / Flash Mode / Flash Adjust. / Wireless Flash Setup / Drive Mode / 1 Shot "6K/4K PHOTO" / Bracketing / Silent Mode / Image Stabiliser / Shutter Type / Ex. Tele Conv. / Flicker Decrease (Photo) / Post-Focus / Motion Pic. Rec Format / Motion Pic. Rec Quality / Rec Quality (My List) / Variable Frame Rate / Time Code Display / Sound Rec Level Disp. / Mute Sound Input / Sound Rec Level Adj. / Sound Rec Level Limiter / XLR Mic Adaptor Setting / Mic. Directivity Adjust / Image Stabiliser / E-Stabilisation (Video) / Boost I.S. (Video) / Image Area of Video / Focus Transition / Live Cropping / Q.MENU / Rec / Playback Switch / Video Record / LVF/Monitor Switch / LVF Magnification / Dial Operation Switch / Preview / Preview Aperture Effect****** / Constant Preview / Level Gauge / Histogram / Luminance Spot Meter / Video Frame Marker / Photo Grid Line / Live View Boost / Monochrome Live View / Night Mode / LVF/Monitor Disp. Style / Video-Priority Display / Status-LCD Display (Video) / Zebra Pattern / LUT View Assist (Monitor) / LUT View Assist (HDMI) / LUT Select / HLG View Assist(Monitor) / HLG View Assist (HDMI) / Sheer Overlay / I.S. Status Scope / WFM/Vector Scope / Anamorphic Desqueeze Display / Colour Bars / Focus Ring Control/ Zoom Control / Destination Card Slot / Wi-Fi / Fan Mode / No Setting / Off (Disable Press and Hold)****** / Restore to Default
PLAY
- Magnify from AF Point / LUT View Assist (Monitor) / HLG View Assist (Monitor) / Anamorphic Desqueeze Display / RAW Processing / 6K/4K PHOTO Bulk Saving / Delete Single / Protect / Rating 1, 2, 3, 4, 5 / Copy / Rec/Playback Switch / LVF/Monitor Switch / Video Record / Night Mode / Card Slot Change / Wi-Fi / Fan Mode / Send Image (Smartphone) / LUT View Assist (HDMI) / HLG View Assist (HDMI) / 6K/4K Photo Play / No Setting / Off (Disable Press and Hold)****** / Restore to Default

LEVEL GAUGE

LEVEL GAUGE
- Yes

OSD LANGUAGE

OSD LANGUAGE
- Japanese, English, German, French, Italian, Spanish, Chinese (Traditional), Chinese (Simplified)

PRINT

PRINT
- PictBridge compatible

INTERFACE

USB
- SuperSpeed USB 3.1 Gen1 Type-C
HDMI****
- Monitor-through
  - 4:2:2 10bit (When [Rec Quality] is set to [4:2:2 10bit] or [4:2:0 10bit].)
    4:2:2 8bit (When [Rec Quality] is set to [4:2:0 8bit].)
    Info Display: ON / OFF (selectable)
    Down Convert: Auto / 4K/30p/25p / 1080p / 1080i / OFF
    HLG View Assist (HDMI): AUTO / MODE1 / MODE2 / OFF (selectable)
- Playback
  - HDMI TypeA / VIERA Link, Audio: Stereo
    59.94Hz: Auto / C4K/60p / C4K/30p / 4K/60p / 4K/30p / 1080p / 1080i / 720p / 480p
    50.00Hz: Auto / C4K/50p / C4K/25p / 4K/50p / 4K/25p / 1080p / 1080i / 720p / 576p
    24.00Hz: Auto / C4K/24p / 4K/24p / 1080p
Remote input
- φ2.5mm
External microphone / external audio device input
- φ3.5mm for external microphone / external audio device
  MIC (Plug-in Power) / MIC / LINE is selectable.
  Stereo/Lens Auto/Shotgun/Super Shotgun/Manual is selectable when attaching DMW-MS2 (sold separately).
Headphone output
- φ3.5mm
Microphone
- Stereo, Wind Noise Canceller: OFF / Low* / Standard / High *When attaching DMW-MS2 (sold separately).
XLR microphone
- Yes with DMW-XLR1 (sold separately)
Speaker
- Monaural
SD card slot
- Slot 1, Slot 2
TC IN/OUT
- Yes with BNC Converter Cable (bundled)
Fan
- Auto1 / Auto2 / Normal / Slow
Tally lamp
- Yes (front/rear)

WIRELESS

Wi-Fi
- 2.4GHz (STA/AP) (IEEE802.11b/g/n)
  5GHz (STA) (IEEE 802.11a/n/ac) *5GHz Wi-Fi is not available in some countries.
  1-13, 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 132, 136, 140, 149, 153, 157, 161, 165 ch
Bluetooth
- Bluetooth® v4.2 (Bluetooth Low Energy (BLE))

DUST AND SPLASH RESISTANT*

DUST AND SPLASH RESISTANT*
- Yes.
  *Dust and Splash Resistant does not guarantee that damage will not occur if this camera is subjected to direct contact with dust and water.

POWER

Battery
- Li-ion Battery Pack (7.4V, 3050mAh, 23Wh) (bundled)
  USB power supply, USB power charging
Battery life (CIPA standard)
- Approx. 400 images (rear monitor), 380 images (LVF), 1,150 images (Power Save LVF mode*) with S-R24105
  *Under the test conditions specified by Panasonic based on CIPA standard. When the time to get in the sleep mode is set to 1 sec.
Battery grip
- DMW-BGS1 (sold separately)

DIMENSIONS / WEIGHT

Dimensions (W x H x D)
- Approx. 151.0 x 114.2 x 110.4 mm / 5.94 x 4.50 x 4.35 inch (excluding protrusions)
Weight
- Approx. 1,164g / 2.57 lb (SD Memory Card x 1, Battery, Body)
  Approx. 1,052g / 2.32 lb (Body only)

OPERATING ENVIRONMENT

Operating temperature*****
- -10oC to 40oC (14oF to 104oF)
Operating humidity
- 10%RH to 80％RH

STANDARD ACCESSORIES

Software
- Recording
  - LUMIX Tether
    ・ This software is used to control a Panasonic digital camera from a PC. It allows you to change various settings of the camera, perform remote recording, and save remotely recorded images to the PC. Check the site below to download and install the software.
    http://panasonic.jp/support/global/cs/soft/download/d_lumixtether.html (For Windows / Mac)
- Playback / Editing
  - ・ The software to edit and playback images on computer is not bundled with this camera. To do this, PHOTOfunSTUDIO 10.1PE is available for download at Panasonic website using computer connected to the Internet.
    https://panasonic.jp/support/global/cs/soft/download/d_pfs1001pe.html(For Windows)
    ・ The software to process RAW file on computer is not bundled with this camera. To do this, SILKYPIX Developer Studio is available for download at Ichikawa Soft Laboratory's website using computer connected to the Internet.
    http://www.isl.co.jp/SILKYPIX/english/p/ (For Windows / Mac)
Standard accessories
- Body Cap, Hot Shoe Cover, Eye Cup, Flash Synchro Socket Cap, Cover for the Battery Grip Connector, Shoulder Strap, Battery Pack, Battery Charger, AC Adaptor, AC Mains Lead, USB Connection Cable (C-C), USB Connection Cable (A-C), BNC Converter Cable, Cable Holder

  ・ The DC-S1H Operating Instructions for advanced features is available for downloaded at Panasonic LUMIX Customer Support Site using PC, smartphone or tablet connected to the Internet.

INTERCHANGEABLE LENS-1

Lens Name
- LUMIX S 24-105mm F4 MACRO O.I.S.
Lens Construction
- 16 elements in 13 groups (2 aspherical ED lenses, 2 aspherical lenses, 1 UED lens, 2 ED lenses)
Mount
- L-Mount
Optical Image Stabiliser
- Yes
Focal Length
- f=24-105mm
Aperture Type
- 9 diaphragm blades / Circular aperture diaphragm
Maximum Aperture
- F4.0
Minimum Aperture
- F22
Closest Focusing Distance
- 0.30m / 0.98ft
Maximum magnification
- Approx. 0.5x
Diagonal Angle of View
- 84°(Wide) - 23°(Tele)
Dust and Splash Resistant
- Yes
Recommended Operating Temperature
- -10oC to 40oC (14oF to 104oF)
General
- Filter Size
  - φ77mm
- Max. Diameter
  - φ84mm / 3.31inch
- Overall Length
  - Approx. 118mm / 4.65inch (from the tip of the lens to the base side of the lens mount)
- Weight [g]
  - Approx. 680g (excluding lens cap, lens rear cap and lens hood)
- Weight [oz]
  - Approx. 23.99oz (excluding lens cap, lens rear cap and lens hood)
- Standard Accessories
  - Lens cap, Lens rear cap, Lens hood, Lens storage bag

NOTE

NOTE
- *** About motion picture recording / 6K PHOTO/4K PHOTO recording
  - 6K PHOTO is a high speed burst shooting function that cuts a still image out of a 4:3 or 3:2 video footage with approx. 18-megapixel (approx. 6000 x 3000 effective pixel count) that the 6K image manages.
  - Use a card with SD Speed Class with ""Class 4"" or higher when recording motion pictures in [AVCHD] or [MP4(under 28Mbps)].
  - Use a card with SD Speed Class with ""UHS-I / UHS-II UHS Speed Class 3 (U3)"" when recording motion pictures with [MP4] in [4K], [MOV], [VFR], [6K PHOTO] or [4K PHOTO].
  (SD speed class is the speed standard regarding continuous writing.)
  - Video Speed Class 60 or higher is required for ALL-Intra 400Mbps recording. Use of SD Memory Card with Video Speed Class 60 or higher is recommended for C4K/4K ALL-Intra video recording.
  - MP4 motion pictures with [MP4] in [4K]:
  - When using an SDHC memory card: You can continue recording without interruption even if the file size exceeds 4 GB, but the motion picture file will be divided and recorded/played back separately.
  - When using an SDXC memory card: You can continue recording without interruption even if the file size exceeds 96 GB or 3 hours 4 minutes in length, but the motion picture file will be divided and recorded/played back separately.
  - MP4 motion pictures with [MP4] in [FHD]:
  - You can continue recording without interruption even if the file size exceeds 4 GB or 30 minutes in length, but the motion picture file will be divided and recorded/played back separately.
  - 4:2:2 10-bit recording is a recording mode for film production and the video needs to be processed on PC.
  The original video cannot be played on standard TV, Blu-ray Disc™ recorder and Blu-ray Disc™ player.
  It may cause problems such as freezing when played on these devices.
  - When the ambient temperature is high or continuous recording is performed, the camera may stop the recording to protect itself. Wait until the camera cools down.

  **** For [6K] [5.9K] [5.4K] [C4K/60p] [C4K/50p] [4K/60p] [4K/50p] video output, use an HDMI2.0 cable that has the HDMI logo on it, and that is described as""4K compatible"".

  ***** The camera may stop recording when used in lower or higher than recommended operating temperature: -10 to 40 degrees.

  ****** Firmware must be updated to version 2.0 / 2.1 or later.

  ******* Firmware must be updated to version 2.2.

  ******** Firmware must be updated to version 2.4.

HDMI RAW DATA OUTPUT

Compatible external devices
- Compatible external devices
  - ATOMOS Ninja V 4K HDR Monitor-Recorder (AtomosOS 10.52 or higher)******
    Blackmagic Video Assist 5" 12G HDR, Blackmagic Video Assist 7" 12G HDR (version 3.4 or higher)********
    *This does not guarantee all of the capabilities that the compatible external recorder may have.

Open a new page for printing

4.7 out of 5 stars. 3 reviews

Customer Reviews

READ AND WRITE REVIEWS

Accessories

Lenses

S-R70200

LUMIX S PRO 70-200mm F4 O.I.S.

S-R2060

LUMIX S 20-60mm F3.5-5.6

S-R24105

LUMIX S 24-105mm F4 MACRO O.I.S.

S-S85

L-Mount 85mm Fixed Focal Length Lens

S-R1635

LUMIX S PRO 16-35mm F4

S-E2470

LUMIX S PRO 24-70mm F2.8

S-X50

LUMIX S PRO 50mm F1.4

S-E70200

LUMIX S PRO 70-200mm F2.8 O.I.S.
