Convenient - Remote Controller

Ease of use

Control fan functions with a simple touch of your finger

Ease of flexibility

Preset your fan shut off after selected time range, regardless of selected speed.

On/Off Button

Press On/Off Button to activate or deactivate the ceiling fan.

Speed Button

From slow speed to cooling environment in three easy speeds selection.

Off Timer Button

1, 3, 6 hours Off Timer setting

Sleep Mode Button

1, 3, 6 Hour Sleep Timer function. To gradually reduce fan speed according to the time setting.

Cancel Button

To cancel Sleep mode or to cancel Off Timer

Caring - Sleep Mode

These fan are equipped with Sleep Mode, by which fan speed and timer will gradually reduce until the fan is off. This function not only creates an optimal sleeping environment but also enhances energy saving as well.

* Note:
Sleep mode is disabled at speed 1 and 1 hour setting.
Operation patter will be different subject to different model and setting, please refer to the operation instruction for details.

Safety Policy by Panasonic

Preventive Measures For Safety

Panasonic aims to minimize and reduce accidents to occur. Thus, Panasonic practices safety policy to prevent any dangerous mishaps.

To pursue a higher quality of life, ceiling fans are expected to have more functions and value added features. However, it is also crucial to consider the safety and reliability features of the fan when you select a ceiling fan.

Safety Wire

Problem

Due to improper installation or should malfunction occur, the fan motor may detached from the pipe rod due to factors such as wearing of shaft bolt, etc.

Preventive Measures

The safety wire helps to secure the fan motor with the ceiling hook to prevent the motor from falling when the fan motor detaches from the pipe rod.

If need shorter/longer pipe

Contact qualified installers or authorized Panasonic service dealers for assistance.

Use the original pipe rod

Original pipe rod comes with the safety wire and safety cut-off switch in line with Panasonic safety policy. Also, do ensure the pipe rod is fully tightened to the motor shaft. (Bolt tightening torque is 800 – 1200 N.com)

Wobbling Reduction Mechanism

Problem

Constant wobbling will cause the bolt, motor shaft and pipe rod to wear off which may cause breakage or falling of the fan to happen should the condition worsened.

Preventive Measures

The newly developed anti-wobbling structure helps to reduce wobbling between bolt, motor shaft and pipe rod. It can minimize the parts from wearing off and prevents from detaching the fan.
