Wall Mount VF Pipe Series

from RM 135.00

Easy to Install, Wall Mounted Exhaust Fan

Eliminates moisture, pollutants, and unpleasant odours from the room. Easy installation, safe design and functions, built-in thermal fuse. Ideal for bathrooms.

Please Select Your User Type

Wall Mount VF Pipe Series

from RM 135.00

Features

What Is a Pipe Fan?

Easy to install, compact size, but with secure exhaust ventilation for removing odor and humidity. Recommended for toilet and bathrooms.

Highly Secure Fuse

A thermal safety fuse ensures that no accidents occur, even when there is a spike in current.

Only 2 Steps for Installation

Installation is easy for everyone and can be completed in 2 steps. The ventilation is well-designed to faciliate the installation of product.

Specs

FV-10EGK203

FV-15EGK203

Compact and stylish design

HP motor with well lubricated bearing for long life operation

Reverse flow prevention shutter

Easy installation

Water resistance: IPX4 (outside)

Motor insulation class: E

	FV-10EGK203	FV-15EGK203
Air Volume (CMH [CFM])	77 [45]	165 [96]
Power Consumption (W)	5.0	6.5
R.P.M. (min⁻¹)	2690	2390
Noise Level (dB[A])	33	37
Installation Space (mm)	φ130 - φ140	φ175 - φ185
Weight (kg)	1.0	1.3
Note	Note1: The value in specification table are representative characteristics value at 220V, 50Hz. Note2: R.P.M. data is for reference only, values may vary subject to different conditions. Note3: The noise level is measured at 1 meter from fan.	Note1: The value in specification table are representative characteristics value at 220V, 50Hz. Note2: R.P.M. data is for reference only, values may vary subject to different conditions. Note3: The noise level is measured at 1 meter from fan.
