LH-75CQ1ND
Specs
Display
-
Size
-
190.5 cm
-
-
Aspect Ratio
-
16:9
-
-
Display Area (HxV)mm
-
1649.6(H) × 927.9(V)
-
-
Resolution (HxV)
-
3840(H)x2160(V)
-
-
Pixel Pitch
-
0.4296mm(H) × 0.4296 mm(V)
-
-
Back Light Unit
-
DLED
-
-
Brightness (typ)
-
500 cd/m²
-
-
Contrast Ratio
-
1200:1
-
-
High Haze
-
Yes,Haze 28%
-
-
Viewing Angle
-
178°
-
-
Display Orientation
-
Landscape & Portrait
-
-
Operation Time
-
7 daysx24 hours
-
Connectors
-
HDMI IN
-
2 (HDMI 2.0)
-
-
HDMI Output
-
1 (HDMI Daisy chain,Up to 3*3)
-
-
Coaxial/Optical Output
-
Optical*1
-
-
Audio Output
-
1 x 3.5mm
-
-
USB 2.0
-
1 (F/W update / Media Play)
-
-
USB 3.0
-
1 (F/W update / Media Play)
-
-
RS232
-
1
-
-
LAN(RJ45)((10M/100M/1000M))
-
2(IN/OUT)
-
-
USB Type-C
-
1 (DP1.2,PD 65W,Network Sharing(100M))
-
System
-
System Version
-
Android 11
-
-
CPU
-
A55*4
-
-
GPU
-
MaliG51 MP2
-
-
RAM
-
4GB
-
-
ROM
-
32GB
-
-
UI
-
4K
-
Audio
-
Speaker Type
-
Built-in Speaker
-
-
Power
-
2x12W
-
Slot
-
OPS Slot
-
Yes, 80 Pin OPS
-
-
WIFI Slot
-
Yes,SI07B
-
Mechanisms
-
Bezel width(T/L/R/B) mm
-
15.9/15.9/15.9/15.9
-
-
Structure
-
Metal Frame
Metal Rear cover
-
-
Dimension (L*W*H) mm
-
1685.6x963.7x81.6
-
-
Wall-hanging Screw
-
M8*25mm
-
-
VESA (Wall mounting Size)
-
800x400mm
-
-
Dimension(package) L*W*H
-
1863×225×1090mm
-
-
Net Weight
-
34.65kg
-
-
Gross Weight
-
48.15kg
-
Power
-
Power Requirements
-
100-240V~ 50/60Hz
-
-
Standby Power
-
≤0.5W
-
-
Overall Power(nominal power)
-
235W
-
Accessories
-
Remote Control
-
1 pcs
-
Environmental Conditions
-
Operation Temperature
-
0℃ - 45℃
-
-
Operation Humidity
-
10% - 90%
-
-
Storage Temperature
-
-20℃ -60℃
-
-
Storage Humidity
-
10% - 90%
-
-
Altitude Below
-
Below 5000 meters
-
