LUMIX G X VARIO 12-35mm / F2.8 II ASPH. / POWER O.I.S. (H-HSA12035) Micro Four Thirds Lens

SHOP NOW
Add to WishlistRemove from Wishlist

NO ROOM TO ADD MORE PRODUCTS

The wishlist has already reached the maximum number of products

SEE YOUR WISHLIST

H-HSA12035

LUMIX G X VARIO 12-35mm / F2.8 II ASPH. / POWER O.I.S.

A standard zoom lens with full-range, high performance and excellent portability.
Zoom In
Zoom Out
Close
Add to WishlistRemove from Wishlist
H-HSA12035
SHOP NOW

Features

Versatile high performance

Get high F2.8 brightness over the entire zoom range with this high-speed zoom lens. Its focal length of 12-35mm (35mm camera equivalent: 24-70mm) covers wide-angle to standard to medium telephoto shooting. Not only ideal for capturing landscapes while traveling, this lens’s wide diameter gives you top-quality indoor shots too. Perceptive and defocusing effects add to the features, giving you exactly the kind of photos and videos you’re looking for. Its dust/splash/freeze-resistant design also makes it great for shooting outdoors, so you can use it in nearly any weather with a dust/splash/freeze-resistant LUMIX camera and be creative.
Versatile high performance

Dust, splash and freeze-resistant design

LUMIX G X VARIO 12-35mm / F2.8 II ASPH. / POWER O.I.S. is designed to keep shooting in the toughest conditions thanks to its dust- and splash-resistant construction and allows you to shoot in temperatures as low as -10 °C.
･Dust- and splash-resistant does not guarantee that damage will not occur if this lens is subjected to direct contact with dust and water.
Dust, splash and freeze-resistant design

O.I.S. for ultra-sharp photos

Capture what you see on the spur of the moment. Optical image stabilization (O.I.S.) technology built directly into the lens ensures your photos will look great, with sharp, blur-free contours across the entire image.
O.I.S. for ultra-sharp photos

Nano Surface Coating – clarity from all angles

Put an end to unwanted ghosting and flaring – the Nano Surface Coating has been applied to lenses within the system. This special, ultra-thin coating was developed originally by Panasonic to reduce bothersome reflections across the entire light spectrum. The result: crystal-clear pictures even if you’re photographing a light source in the dark.
Nano Surface Coating – clarity from all angles

Ideal for video recording

The lens offers fast, accurate autofocus and smooth aperture changes, critical for the modern content creator, allowing you to record beautiful 4K video and stills without disturbing your subject.
Ideal for video recording

H-HSA12035 lens construction

The optimized configuration has 14 elements in 9 groups, including 4 ASPH, 1 UED and 1 UHR lenses to minimize aberrations and ensure superb resolution.
H-HSA12035 lens construction

H-HSA12035 MTF chart

Realizes excellent sharpness and resolution throughout the zoom range and demonstrates uncompromising expressiveness.
･For lenses that are capable of compensating distortion, the horizontal axis shows the distance from the center of the corrected image.
H-HSA12035 MTF chart

Get Inspired

Specs

Photo of LUMIX G X VARIO 12-35mm / F2.8 II ASPH. / POWER O.I.S. (H-HSA12035) Micro Four Thirds Lens

Size and Weight

Height
67.6mm
Width
67.6mm
Depth
73.8mm
Weight
305g

Approximately. Weight excluding lens cap, lens rear cap and lens hood. Length from the tip of the lens to the base side of the lens mount.

  • Micro Four Thirds System StandardMicro Four Thirds System Standard
  • Nano Surface CoatingNano Surface Coating
  • POWER O.I.S. (Optical Image Stabilizer)POWER O.I.S. (Optical Image Stabilizer)
  • Dust / Splash / Freeze ResistantDust / Splash / Freeze Resistant

Full-range F2.8 standard zoom lens

Dust, splash and freeze-resistant design

POWER O.I.S. (Optical Image Stabilizer)

Standard Accessories

  • Lens cap, Lens rear cap, Lens hood, Lens storage bag

Features

  • Lens Construction

    • 14 elements in 9 groups (4 aspherical lenses, 1 UED lens, 1 UHR lens)

  • Nano Surface Coating

    • Yes

  • Mount

    • Micro Four Thirds mount

  • Optical Image Stabilizer

    • Yes (POWER O.I.S.)

  • Focal Length

    • f=12-35mm (35mm camera equivalent 24-70mm)

  • Aperture Type

    • 7 diaphragm blades / Circular aperture diaphragm

  • Maximum Aperture

    • F2.8

  • Minimum Aperture

    • F22

  • Closest Focusing Distance

    • 0.25m / 0.82ft

  • Maximum magnification

    • Approx. 0.17x / 0.34x (35mm camera equivalent)

General

  • Diagonal Angle of View

    • 84°(Wide) - 34°(Tele)

  • Weatherproof

    • Splash/Dust/Freezeproof

  • Filter Size

    • φ58mm / 2.28inch

  • Max. Diameter

    • φ67.6mm / 2.66inch

  • Overall Length

    • Approx. 73.8mm / 2.91inch (from the tip of the lens to the base side of the lens mount)

  • Weight

    • Approx. 305g / 10.76oz (excluding lens cap, lens rear cap and lens hood)
