| CD, CD-R/ -RW*1 |
CD-DA |
Yes |
| MP3*2 |
Yes |
| AUDIO SYSTEM |
Output Channel |
2ch |
| Power Output-RMS |
Front |
20W (1kHz, 6ohms, 10% THD) |
| Total Power |
40W |
| USB |
Slot |
Yes |
| Playback |
MP3*2 |
Yes |
| HIGH QUALITY SOUND |
Aero Stream Port |
Yes |
| Nanosized Bamboo Cone Speaker |
Yes |
| Digital Music Connection for iPod®/ iPhone®/ iPad® |
Yes |
| Pure Direct Sound System |
Yes |
| Direct-Vocal Surround |
Yes |
| Bluetooth® Re-Master |
Yes |
| D.Bass |
Yes |
| Preset EQ |
yes 4 (Heavy, Clear, Soft, Vocal) + Flat |
| Bass & Treble Control |
Yes |
| NETWORKING |
Panasonic Music Streaming App |
yes*3 |
| Wireless Audio with AirPlay® |
yes*4 |
| Bluetooth® Wireless Technology |
Yes |
| Wireless Audio with DLNA |
Yes |
| USB connection for iPod®/ iPhone®/ iPad® |
yes*5 |
| Wireless CD Playback |
Yes |
| Works with iPhone 5® /iPod Touch ® (5th generation) |
Yes |
| DESIGN |
Wall-Mountable |
Yes |
| Multi Layout Speaker |
Yes |
| Front |
Configuration |
2-way 2 speaker system, Bass-reflex |
| Speaker Unit [Approx.] |
Woofer: 8 cm x 2 |
| TERMINAL |
Analog Audio Input - Speaker Unit(3.5mm) |
yes (AUX/ System port) |
| Analog Audio Output - Docking/ CD Unit(3.5mm) |
yes (System port) |
| TUNER |
Band/ Station Presets |
30-FM |
| Auto Tuning |
Yes |
| RDS |
Yes |
| OTHERS |
Power Supply |
AC 220-240V, 50Hz |
| Power Consumption |
Normal Use [Approx.] - Speaker Unit |
14W |
| Normal Use [Approx.] - Docking/ CD Unit |
23W |
| Standby [Approx.] - Speaker Unit |
0.3W |
| Standby [Approx.] - Docking/ CD Unit |
0.3W |
| Auto Power Off/ Dimmer |
yes / yes |
| DIMENSIONS, WEIGHT |
Dimensions (W x H x D) [Approx.] - Speaker Unit |
570 x 206 x 100 mm |
| Weight [Approx.] - Speaker Unit |
2.8 kg |
| Dimensions (W x H x D) [Approx.] - Docking/ CD Unit |
192 x 206 x 93 mm |
| Weight [Approx.] - Docking/ CD Unit |
0.9kg |
| NOTE |
*1 Playability may vary depending on the contents, discs and quality of the recording.
*2 For content recorded disc media from CD's for your personal use.
*3 App is available on iTunes/Google Play™ .
*4 To use the AirPlay function, this unit must join the same network as the compatible device.
*5 Not all models are compatible. See dealer for details.
Specifications are subject to change without notice. Weight and dimensions are approximate. |
