| POWER |
Power source |
12 V DC, 1.5A (including a digital camera) |
| OPERATING ENVIRONMENT |
Operating temperature |
0℃ to 40℃ (32°F to 104°F) |
| Operating humidity |
10% to 80％ (no condensation) |
| DIMENSIONS / WEIGHT |
Weight |
Approx. 750 g / 24.46 oz (main unit only) |
| Dimensions (W x H x D) |
160 x 64 x 91 mm / 6.30 x 2.52 x 3.58 in (excluding protrusions and HDMI terminal) |
| VIDEO (DIGITAL VIDEO) |
Resolution |
Cinema4K |
4096 x 2160 [24p] |
| QFHD |
3840 x 2160 [29.97p]/3840 x 2160 [25p]/3840 x 2160 [24p]/3840 x 2160 [23.98p] |
| FHD |
1920 x 1080 [59.94p] (3G-SDI Level-A/B)/1920 x 1080 [50p] (3G-SDI Level-A/B)/1920 x 1080 [59.94i]/1920 x 1080 [50i]/1920 x 1080 [29.97PsF]/1920 x 1080 [25PsF]/1920 x 1080 [24PsF]/1920 x 1080 [23.98PsF] |
| HD |
1280 x 720 [59.94p]/1280 x 720 [50p] |
| Color sampling |
Y:Cb:Cr=4:2:2 |
| Bit depth |
8 bits / 10 bits |
| AUDIO (DIGITAL AUDIO) |
Sampling frequencies |
48 kHz (synchronized with video) |
| Audio quantization |
16 bit |
| Headroom |
12 dB |
| INPUT / OUTPUT |
TC IN |
BNC x 1, 1.0-4.0 V [p-p], 10 kΩ |
| AUDIO IN [CH1, CH2] |
XLR (3-pin) x 2, High impedance,/LINE / MIC / +48 V (switchable)/LINE: 0 dBu/MIC: -50 dBu/+48 V: Phantom +48 V compatible, -50 dBu |
| SDI OUT [1, 2, 3, 4] |
BNC x 4, 0.8 V [p-p], 75 kΩ/Embedded audio: 2 channel, embedded timecode |
| HDMI OUT |
HDMI type A (VIERA link not supported), 2 channels (linear PCM) |
