OLED 4K Ultra HD TV TH-77EZ1000U
| Picture Quality | Display | Panel | 4K ULTRA HD/Master OLED HDR |
|---|---|---|---|
| 4K PRO | Y | ||
| Bright Panel | Ultra Bright Panel | ||
| Screen Resolution | 3,840 (W) x 2,160 (H) | ||
| Panel Drive | OLED Superb Motion Drive | ||
| Picture Mode | Dynamic/Normal/Cinema/True Cinema/THX 4K (Cinema/Bright Room)/Custom/Professional1/Professional2 (isfccc) | ||
| Signal Processor | Studio Color HCX2 | ||
| Hexa Chroma Drive | 4K Hexa Chroma Drive PRO | ||
| Vivid Digital Pro | — | ||
| 4K Upscaling | Y | ||
| Ultra HD Premium*¹ | Y | ||
| HDR | Y (Multi HDR Support) | ||
| Pixel Dimming | Y | ||
| Local Dimming | — | ||
| Adaptive Backlight Dimming | — | ||
| Noise Reduction | Y(Multi Noise) | ||
| THX Certified Display*² | Y | ||
| 4K Pure Direct | Y | ||
| isf Mode | Y | ||
| 3D Look Up Table | Y | ||
| 3D | — | ||
| Sound Quality | Surround | VR-Audio True Surround+ | |
| Speakers | Dynamic Blade Speaker: Tweeter x 2, Squaker x 4, Woofer x 8, Quad Passive Radiator | ||
| Speaker Output | 80 W (20 W x 2 + 20 W x 2) | ||
| Sound Mode | Standard/Music/Ambience/User | ||
| Smart Features | Smart TV | Y | |
| my Home Screen | Y (2.0) | ||
| Info Frame | Y | ||
| Voice Interaction | Voice Interaction | Y | |
| Voice Guidance | Y | ||
| EPG | SI, 7 days | ||
| On Screen Display Menu Languages | English / Chinese (Simplified) | ||
| Unique Processing Engine | Quad-Core Pro | ||
| Wireless LAN Built-in | Y | ||
| Panasonic Media Center (App) | Panasonic Media Center (App) | Y | |
| TV Anytime*³ | Y | ||
| USB-HDD Recording | Y | ||
| Panasonic TV Remote Apps | Panasonic TV Remote Apps | Y | |
| Swipe & Share | Y | ||
| Smart Calibration | Y | ||
| Internet Apps | Internet Apps | Y | |
| Web Browser*⁴ | Y | ||
| Hbb TV | Y | ||
| Mirroring | Y (Easy) | ||
| DLNA*⁵ | Y (DTCP-IP/DMP/DMR/DMS) | ||
| Bluetooth*⁶ | Y (Keyboard/Mouse) | ||
| Media Player | Media Player | Y (2.0 *⁷) | |
| Support Format | AVI/HEVC/MKV/WMV/MP4/M4v/FLV/3GPP/VRO/VOB/TS/PS, MP3/AAC/WMA Pro/FLAC/Apple Lossless/WAV, JPEG | ||
| Double USB Sharing | Y | ||
| Teletext Reception | 2000P | ||
| Multi Window | 2T PAP | ||
| Hotel Mode | Y | ||
| VIERA Link | Y | ||
| Energy Data | Visible Screen Size (diagonal) | 164 cm | |
| Rated Power Consumption | 2.28 A | ||
| Standby Power Consumption | 0.50 W | ||
| Power Supply | AC 220 - 240 V, 50/60 Hz | ||
| Ambient Sensor | Y | ||
| Terminal | Twin HD Tuner | Y | |
| Digital Tuner Reception | DVB-T | ||
| Analogue Tuner | 4-System (PAL/NTSC/M-NTSC/PAL-60) | ||
| HDMI | HDMI*⁸ | 2 (side), 2 (rear) | |
| HDMI (4K 60/50p with HDCP2.2) | 4 | ||
| Support Feature | Audio Return Channel (Input 2) | ||
| USB | 3 (1 side, 2 rear; USB 3.0 x 1, USB 2.0 x 2) | ||
| LAN Port | 1 | ||
| SD Card | — | ||
| Component Video Input shared with Composite | RCA phono type x 1 (side) | ||
| Composite Video Input | RCA phono type x 1 (side) | ||
| Digital Audio Output (Optical) | 1 (rear) | ||
| Analogue Audio Output | — | ||
| Headphone Output | 1 (side) | ||
| GENERAL | Included Accessory*⁹ | Touch Pad Remote / TV Remote | |
| Dimensions (W x H x D) (w/o stand) | 1723 x 998 x 52 mm | ||
| Dimensions (W x H x D) (with stand)*10 | 1723 x 1090 x 388 mm | ||
| Weight (w/o stand) | 35.0 kg | ||
| Weight (with stand) | 44.0 kg | ||
| VESA / Wall Mountable | Y | ||
| NOTE | *1 Ultra HD PremiumTM logo is a trademark of the UHD Alliance, Inc. *2 THX and the THX logo are trademarks of THX Ltd. which are registered in some jurisdictions. The THX 3D logo is a trademark of THX Ltd. All rights reserved. *3 Due to network conditions or certain broadcaster restrictions, this function may not be available. *4 The Web Browser cannot display some web pages correctly. And viewable contents by VIERA Web Browser are subject to the following conditions; - viewable contents may vary depend on models, - viewable contents may differ from those for PC, - viewable contents may be limited. *5 DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance. *6 HID (Human Interface Device Profile) compliant keyboards are available. The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. *7 To playback HDR, a HDR source is required (H.264 or H.265(ST2084 or HLG format)). *8 The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries. *9 Not all the accessories are listed here. *10 Dimension with recommended pedestal style. | ||
