| Feature |
• Dual function-rotary hammer or drill
• Two-speed hammering selection
• Two speed drilling selection withvariable speed control / reversible
• Slow start switch for accurate drilling with a clean finish
• Ergonomic soft rubber grip for stress reduction
• 360 auxiliary side handle with built-in depth gauge
• 3/4” SDS-plus bit system
• Hammering force: 23.6 kN
• LED light to support work
• With 2 battery packs, battery charger (EY0L82) and carrying case |
| Speed at No load (Rotation only) |
Hard Mode (High) |
0-920 rpm |
| Soft Mode (Slow) |
0-500 rpm |
| Blows Rate per Minute (Rotation with hammering) |
Hard Mode (High) |
0-4,500 bpm |
| Soft Mode (Slow) |
0-2,800 bpm |
| Size (LxHxW) / Weight (including battery pack) |
319 mm x 203 mm x 83 mm / 3.85 kg |
| Battery Pack and Charging time (using EY0L82B) |
28.8V / 3.0Ah (EY9L82B)
Usable:60min. / Full:80min. |
| Capacity |
Concrete (At concrete strength of medium hardness) |
ø6 mm x 30 mm |
150 holes /charge |
| ø8 mm x 100 mm |
30 holes /charge |
| ø12.5 mm x 40 mm |
70 holes /charge |
| ø14.5 mm x 90 mm |
20 holes /charge |
| ø20 mm x 40 mm |
30 holes /charge |
