SC-PMX152 (DISCONTINUED PRODUCT)
| PLAYABLE DISCS | CD, CD-R/-RW | CD-DA | yes |
|---|---|---|---|
| MP3 | yes | ||
| AUDIO SYSTEM | Output Channel | 2ch | |
| Power Output (RMS) Total Power | 120W | ||
| Front | 60W (1kHz, 3ohms, 10% THD) | ||
| USB | Slot | yes (x2) | |
| USB Standard | USB 2.0 High Speed | ||
| Playback | MP3, AIFF, AAC, FLAC (up to 192kHz/24bit), WAV (up to 192kHz/24bit), DSD (5.6MHz/2.8MHz) | ||
| Battery Charge | - | ||
| Tuner | Band/Station Presets | FM/ 30, DAB Plus/ 20 | |
| RDS | - | ||
| Auto Tuning | yes | ||
| SMART NETWORKING | Multi-room Audio with Qualcomm® Allplay™ | yes | |
| Wireless LAN System | yes | ||
| Home Network Music Playback | yes | ||
| AirPlay | yes | ||
| Wi-Fi Frequency Range | yes (5GHz/ 2.4GHz) | ||
| Ethernet (10 Base-T/ 100 Base-TX) | yes | ||
| WPS Support | yes | ||
| Bluetooth® Wireless Technology | yes | ||
| Panasonic Music Streaming App | yes | ||
| NFC (One-Touch Connection) | - | ||
| USB Connection for iPod/ iPad/ iPhone | yes*2 (Playback/ Charging) | ||
| Re-streaming (Bluetooth®, CD, Radio, USB, AUX) | yes*3*4 | ||
| Net Preset Button (for Internet Radio) | -* | ||
| Number of Preset | 6 | ||
| HIGH QUALITY SOUND | Full Digital Amplifier System | yes | |
| LincsD-Amp | yes (3rd generation) | ||
| VGDA (Variable Gain Digital Amplifier) | yes | ||
| Virtual Battery Power Supply | yes | ||
| Built-in Power Conditioner | yes | ||
| USB-DAC Function | MP3, AIFF, FLAC (up to 192kHz/24bit), WAV (up to 192kHz/24bit), DSD (5.6MHz/2.8MHz) | ||
| XBS Master | yes | ||
| CD High-Res Re-Master | yes | ||
| MP3 Re-Master | yes | ||
| Bluetooth® Re-Master | yes | ||
| Super Sonic Tweeter | yes | ||
| Bamboo Plant Opal Cone | yes (Woofer) | ||
| Bamboo Charcoal PP Cone | - | ||
| Preset EQ | 4 (Heavy, Soft, Clear, Vocal) + Flat | ||
| Bass & Treble Control | yes (Knob on main unit) | ||
| SPEAKER | FRONT | Configuration | 3-way 3 speaker system |
| Speaker Unit | Woofer: 14 cm Cone Type Tweeter: 1.9 cm Dome Type Super Sonic Tweeter: 1.2 cm Piezo Type | ||
| TERMINAL | LAN Terminal | yes | |
| Analogue Audio Input (AUX) | Pin Jack | yes | |
| 3.5 mm Jack | - | ||
| Headphone Output | yes | ||
| OTHERS | Power Supply | AC 220-240V, 50Hz | |
| Power Consumption | Normal Use [Approx.] | 45W | |
| Standby [Approx.] | 0.4W*5 | ||
| Auto Power Off/ Dimmer | yes/ yes | ||
| Programmable Timer | Sleep / Clock / Play Timer | ||
| Display | Dot Matrix FL | ||
| Remote Control | yes | ||
| DIMENSIONS, WEIGHT | Main Unit(W x H x D) | 211 x 114 x 267 mm*6 | |
| Weight | 3.0 kg | ||
| Front Speaker(W x H x D) | 161 x 238 x 264 mm *6 | ||
| Weight | 3.0 kg | ||
| NOTE | *1DownloadontheAppStore.Download onGooglePlay™. | ||
| NOTE | *2Notallmodelsarecompatible.Seedealerfordetails. | ||
| NOTE | *3Whenyouusetheapp“PanasonicMusicStreaming”tostreammusiconthissystemtootherAllPlayspeakers | ||
| NOTE | ・Thevideoandaudiooutputmaynotbesynchronisedduringplaybackofvideocontents. | ||
| NOTE | ・IfmusicisstreamedtootherAllPlayspeakersformorethan8hours,theotherAllPlayspeakerswillautomaticallystopplayingthemusic.(Thespecificationsaresubjecttochangewithoutnotice.) | ||
| NOTE | *4DSD5.6MHzfilescanbeplayedonthisunitonly.(5.6MHzfilescannotre-streamtootherunits.) | ||
| NOTE | *5Standby(Bluetoothstandbyon)powerconsumptionapproximately0.5W(PMX152),0.45W(PMX82) | ||
| NOTE | *6Weightanddimensionsareapproximate. | ||
| NOTE | ●Playabilitymayvarydependingonthecontents,discsandqualityoftherecording.Forcontentsrecordedforyourpersonaluse. | ||
| NOTE | ●Specificationsaresubjecttochangewithoutnotice.Allnumbersgivenhereareapproximate. | ||
| NOTE | *Notice of support termination of internet radio app “AllPlay Radio” | ||
| TRADEMARK NOTICE | MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. | ||
| TRADEMARK NOTICE | DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance. | ||
| TRADEMARK NOTICE | Apple, iPhone, iPhone 5 and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. | ||
| TRADEMARK NOTICE | AirPlay, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. | ||
| TRADEMARK NOTICE | Google Play is a trademark of Google Inc. | ||
| TRADEMARK NOTICE | The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. | ||
| TRADEMARK NOTICE | Other trademarks and trade names are those of their respective owners. | ||
| TRADEMARK NOTICE | The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries. | ||
| TRADEMARK NOTICE | Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. Used with permission. | ||
| TRADEMARK NOTICE | AllPlay is a trademark of Qualcomm Connected Experiences, Inc., registered in the United States and other counties. Used with permission. | ||
