CD Micro System SC-PMX100BGN
| PLAYABLE DISCS | CD, CD-R/-RW | CD-DA | yes |
|---|---|---|---|
| MP3 | yes | ||
| AUDIO SYSTEM | Output Channel | 2ch | |
| USB | Slot | yes (x2) | |
| USB Standard | USB 2.0 High Speed | ||
| TUNER | Band/Station Presets | FM/ 30, DAB Plus/ 20 | |
| RDS | - | ||
| Auto Tuning | yes | ||
| SMART NETWORKING | Multi-room Audio with Qualcomm® Allplay™ | yes | |
| Wireless LAN System | yes | ||
| DLNA | yes | ||
| AirPlay | yes | ||
| Wi-Fi Frequency Range | yes (5GHz/ 2.4GHz) | ||
| Ethernet (10 Base-T/ 100 Base-TX) | yes | ||
| WPS Support | yes | ||
| Bluetooth® Wireless Technology | yes | ||
| Panasonic Music Streaming App | yes*1 | ||
| NFC (One-Touch Connection) | yes | ||
| USB Connection for iPod/ iPad/ iPhone | yes (Playback/ Charging)*2 | ||
| Re-streaminig (Bluetooth®, CD, Radio, USB, AUX) | yes | ||
| HIGH QUALITY SOUND | Full Digital Amplifier System | yes | |
| LincsD-Amp | yes (3rd generation) | ||
| VDGA (Variable Digital Gain Amplifier) | yes | ||
| Virtual Battery Power Supply | yes | ||
| USB-DAC Function | MP3, AIFF, ALAC, FLAC (up to 192kHz/24bit), WAV (up to 192kHz/24bit) | ||
| XBS Master | yes | ||
| Bluetooth® Re-Master | yes | ||
| Super Sonic Tweeter | yes | ||
| Bamboo Plant Opal Cone | yes (Woofer) | ||
| Bass & Treble Control | 4 (Heavy, Clear, Soft, Vocal) + Flat | ||
| Surround | yes (Knob on main unit) | ||
| SPEAKER SYSTEM | Front | Configuration | 3-way 3 speaker system |
| Speaker Unit | Woofer: 14 cm Cone Type | ||
| Speaker Unit | Tweeter: 1.9 cm Dome Type | ||
| Speaker Unit | Super Sonic Tweeter: 1.2 cm Piezo Type | ||
| TERMINAL | LAN Terminal | yes | |
| Analogue Audio Input (AUX) | Pin Jack | yes | |
| 3.5 mm Jack | - | ||
| Headphone Output | yes | ||
| OTHERS | Power Supply | AC 220-240V, 50Hz | |
| Power Consumption | Normal Use [Approx.] | 45W | |
| Standby [Approx.] | 0.45W*3 | ||
| Auto Power Off/ Dimmer | yes/ yes | ||
| Programmable Timer | PLAY/ SLEEP | ||
| Display | Dot Matrix FL | ||
| Remote Control | yes | ||
| DIMENSIONS, WEIGHT | Main Unit | Dimensions (W x H x D) | 211 x 114 x 267 mm*5 |
| Weight | 3.0 kg*5 | ||
| Front Speaker | Dimensions (W x H x D) | 161 x 238 x 264 mm*5 | |
| Weight | 3.0 kg*5 | ||
| NOTE | *1 Download on the App Store. Download on Google Play™. | ||
| NOTE | *2 Not all models are compatible. See dealer for details. | ||
| NOTE | *3 Standby (Bluetooth standby on) power consumption approximately 0.5W. | ||
| NOTE | *4 Standby (Bluetooth standby on) power consumption approximately 0.45W. | ||
| NOTE | *5 Weight and dimensions are approximate. | ||
| NOTE | Playability may vary depending on the contents, discs and quality of the recording. For contents recorded for your personal use. | ||
| NOTE | Specifications are subject to change without notice. All numbers given here are approximate. | ||
| TRADEMARK NOTICE: | MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson. | ||
| TRADEMARK NOTICE: | DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance. | ||
| TRADEMARK NOTICE: | Apple, iPhone, iPhone 5 and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. (TENTATIVE) | ||
| TRADEMARK NOTICE: | AirPlay, iPad, iPhone, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries. | ||
| TRADEMARK NOTICE: | Google Play is a trademark of Google Inc. | ||
| TRADEMARK NOTICE: | The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. | ||
| TRADEMARK NOTICE: | The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries. | ||
| TRADEMARK NOTICE: | Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. Used with permission. AllPlay is a trademark of Qualcomm Connected Experiences, Inc., registered in the United States and other counties. Used with permission. | ||
