Stereo Speaker System SC-ALL5CD
| AUDIO SYSTEM | Output Channel | 2ch | |
|---|---|---|---|
| Power Output (RMS) | Total Power | 40W | |
| PLAYABLE DISCS | CD, CD-R/-RW | CD-DA | yes |
| MP3 | yes | ||
| Slot | yes | ||
| USB Standard | USB 2.0 Full Speed | ||
| Playback | MP3 | ||
| Battery Charge | yes (1.5A only) | ||
| PLAYABLE FORMAT | MP3/ AAC/ WAV/ FLAC/ ALAC | yes | |
| TUNER | Band/Station Presets | FM/ 30, DAB, DAB Plus/ 20 | |
| SMART NETWORKING | Multi-room Audio with Qualcomm® Allplay™ | yes | |
| Wireless LAN System | yes | ||
| Party Mode*1/ Multi-zone*2 | yes/ yes | ||
| Wi-Fi Frequency Range | yes (5GHz/ 2.4GHz) | ||
| Ethernet (10 Base-T/ 100 Base-TX) | yes | ||
| WPS support | yes | ||
| Wireless Audio with DLNA | yes | ||
| Bluetooth® Wireless technology | yes | ||
| Panasonic Music Streaming App*3 | yes | ||
| NFC(One-Touch Connection)*4 | yes | ||
| Re-streaminig (Bleutooth®, CD, Radio, USB, AUX) | yes | ||
| Stereo Paring | yes | ||
| HIGH QUALITY SOUND | LincsD-Amp | yes(3rd generation) | |
| XBS Mater | yes | ||
| Bluetooth® Re-master | yes | ||
| SPEAKER SYSTEM | Front Speaker | Configuration | 2-way 2 speakers system (Dual Passive Radiator) |
| Speaker Unit | 6.5 cmFull Range x 2 | ||
| Bass Expand | Passive Radiator x2 x2 | ||
| TERMINAL | Optical Digital Audio Output | - | |
| Analogue Audio Output | Stereo (Gold Coating Pin Jack) | - | |
| Analogue Audio Input (AUX) | Stereo (3.5mm Jack) | yes | |
| LAN (Ethernet) Terminal | 10 Base-T/ 100 Base-TX | yes | |
| OTHERS | Power Supply | AC 220-240/250V, 50Hz | |
| Power Consumption | Normal Use | 25W | |
| Standby | 0.3W*5 | ||
| Wall-Mountable | yes | ||
| Personalized (Preset) Buttons for Internet radio | yes (6 presets: no direct buttons App/ Remote control operation) | ||
| Music Alarm | yes | ||
| Clock Display | yes | ||
| Remote Control | yes | ||
| DIMENSIONS, WEIGHT | Main Unit(W x H x D) | 533 x 203 x 97.5 mm | |
| Main Unit(W x H x D) | 2.7 kg | ||
| NOTE | *1 Party Mode; playing a single sound source simultaneously through multiple speakers. The maximum number of speakers is limited (Under study). | ||
| NOTE | *2 Multi Zone; playing each of multiple songs within the same network to separate speakers. The maximum number of sound sources is limited (Under study). When using a subscription service, this function depends on the conditions of the service provider (Under study). | ||
| NOTE | *3 Download on the App Store. Download on Google Play™. | ||
| NOTE | *4 To use NFC without downloading App, an OS Version 4.1 or later AndroidTM device is requrired. The installation of the Panasonic Music Streaming App allows use of an Android smartphone or tablet with the NFC function and OS Version 4.1 or earlier. | ||
| NOTE | *5 The other connected devices have to be turned off. Standby (Bluetooth standby on) power consumption approximately 0.4W(ALL5CD). | ||
| NOTE | Specifications are subject to change without notice. All numbers given here are approximate. | ||
| TRADEMARK NOTICE: | Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc. | ||
| TRADEMARK NOTICE: | Google Play is a trademark of Google Inc. | ||
| TRADEMARK NOTICE: | The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. | ||
| TRADEMARK NOTICE: | The N-Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries. | ||
| TRADEMARK NOTICE: | Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries. Used with permission. AllPlay is a trademark of Qualcomm Connected Experiences, Inc., registered in the United States and other counties. Used with permission. | ||
