SC-HTB490 Soundbar with Wireless Subwoofer

See product page
Photo of SC-HTB490 Soundbar with Wireless Subwoofer

Amplifier

  • Amp Type

    • 2.1 ch

  • RMS Output Power

    • Total RMS Stereo Mode Power

      • 320 W

    • Front Speaker (Left / Right)

      • 80 W + 80 W (1 kHz, 4 Ω)

    • Subwoofer

      • 160 W (100 Hz, 3 Ω)

Speaker System

  • Front Speaker (Left / Right)

    • Type

      • 1 way, 1 speaker system (Bass reflex)

    • Speaker Unit

      • Full Range 4.5 x 12 cm, Cone type x 2 pcs

    • Bass Expand

      • Bass Reflex Port

  • Subwoofer

    • Type

      • 1 way, 1 speaker system (Bass reflex)

    • Speaker Unit

      • Woofer 16cm, Cone Type x 1pc

    • Bass Expand

      • Bass Reflex Port

    • Wireless

      • Yes

Network

  • Bluetooth®

    • Version

      • Bluetooth® Ver 4.2

    • Class

      • Class 2

    • Codec

      • SBC

    • Bluetooth Standby

      • Yes

    • Connectivity

      • Multi-Pairing (MAX 8 Devices)

  • WiFi

    • Standard

      • -

    • Frequency Band

      • -

  • Chromecast built-in

    • -

Terminal

  • HDMI

    • Input

      • -

    • Output

      • x 1 (ARC)

  • Audio Input

    • Optical Input

      • x 1

    • Coaxial Digital Input

      • -

    • Analog Input (Pin Jack / φ3,5)

      • -

  • Other

    • IR System Terminal

      • -

    • USB Port

      • x 1 (Play)

    • LAN

      • -

Function

  • Sound Function

    • Surround

      • Virtual Surround

    • SOUND MODE

      • Standard, Cinema (Surround), Sports(Surround), Music, News

    • Bass Boost

      • -

    • Subwoofer Level Adjustment

      • Yes (5 levels)

    • Clear-mode Dialog

      • -

    • Dialog Level Control

      • -

    • Low-volume Mode

      • -

    • Auto Gain Control

      • -

    • Direct music mode with remote control

      • -

    • Auto LIP Synchronization with HDAVI Control

      • -

  • Decoder Function / Format

    • LPCM

      • Yes (Max 2ch)

    • Dolby Digital

      • Yes

    • Dolby Digital +

      • -

    • Dolby True HD

      • -

    • Dolby Atmos

      • -

    • DTS Digital Surround

      • Yes

    • DTS ES

      • -

    • DTS 96/24

      • -

    • DTS-HD HR

      • -

    • DTS-HD High Resolution Audio

      • -

    • DTS-HD Master Audio

      • -

    • DTS : X

      • -

    • DTS Virtual : X

      • -

  • HDMI Function

    • CEC

      • Yes

    • Audio Return Channel(for HDMI Output)*¹

      • Yes

    • LPCM Multi Channel Input (HDMI Input)

      • -

    • 1080p, Deep Color, x.v. Color

      • -

    • 4K Pass through

      • -

    • FULL HD 3D COMPATIBLE

      • -

    • HDMI UP Conversion

      • -

    • HDR10 Pass Through

      • -

    • HDR10+ Pass Through

      • -

    • Dolby Vision Pass Through

      • -

  • USB Function

    • USB Host Play

      • Yes

    • Service Use

      • Yes

    • Customer Software Update

      • Yes

    • USB Standard

      • USB 2.0 full speed

    • Charging

      • -

    • Playback Format

      • MP3

Main Unit Setting

  • Wall Mountable

    • Yes

  • Matching TV Size

    • 43 inch and above

General

  • Main Unit

    • Power Supply

      • AC 220 - 240 V, 50 Hz

    • Power Consumption *² Normal Use

      • 24 W

    • Power Consumption *² Network Standby Off

      • 0.5 W

    • Power Consumption *² Network Standby On

      • 2 W

    • LED Indication

      • Yes x2 (Multi Color)

  • Subwoofer

    • Power Supply

      • AC 220 - 240 V, 50 Hz

    • Power Consumption *² Normal Use

      • 22 W

    • Power Consumption *² Network Standby

      • 0.5 W

  • Dimmer

    • Bright, Dark

  • Auto OFF

    • Yes

Dimension

  • Main Unit (W x H x D)

    • For table top layout

      • 800 x 56 x 101 mm

    • For table top layout with High adjustable legs

      • 800 x 72 x 101 mm

    • For table top layout with Low adjustable legs

      • -

    • For wall mount layout

      • 800 x 64 x 108 mm

  • Subwoofer (W x H x D)

    • 171 x 382 x 363 mm

Weight

  • Main Unit

    • 1.9 kg (approx.)

  • Main Unit (Wall Mount)

    • 2.0 kg (approx.)

  • Subwoofer

    • 5.7 kg

Color

  • Black

Accessories

  • Remote Control

    • Yes

  • Dry Batteries for Remote Control

    • Yes (Button Type)

  • AC Cord

    • Yes (Main Unit 1.5m / Subwoofer 1.2m)

  • Wall Mount Bracket

    • Yes

  • IR System Cable

    • -

  • Optical Degital Cable

    • -

  • Operating Instruction

    • WEB OI

  • Quick Setting Guide

    • -

Note:

  • *1 ARC　(Audio Return Channel) compatible TV is required.
    *2 Specifications are subject to change without notice. All numbers given here are approximate.
