| Features |
Lens Construction |
10 elements in 9 groups (1 ED lens) |
| Mount |
Micro Four Thirds mount |
| Optical Image Stabilizer |
No |
| Focal Length |
f=8mm (35mm camera equivalent 16mm) |
| Aperture Type |
7 diaphragm blades / Circular aperture diaphragm |
| Aperture |
F3.5 |
| Minimum Aperture |
F22 |
| Closest Focusing Distance |
0.1m / 0.33ft |
| Maximum magnification |
Approx. 0.20x / 0.40x (35mm camera equivalent) |
| General |
Diagonal Angle of View |
180° |
| Projection system |
Equisolid angle projection system |
| Filter Size |
Front : Mounting not possible / Rear : Sheet filter holder 22mm / 0.86in x 22mm / 0.86in |
| Max. Diameter |
φ60.7mm / 2.39 in |
| Overall Length |
Approx. 51.7mm / 2.04 in (from the tip of the lens to the base side of the lens mount) |
| Weight [g] |
165 |
| Weight [oz] |
5.82 |
| Standard Accessories |
Lens Cap |
| Standard Accessories |
Lens Rear Cap |
| Standard Accessories |
Lens Storage Bag |
