CS-YN30YKF
Powerful cooling with 25M Long Reach Airflow.
Enjoy comfortable cooling in optimal environment with Panasonic innovative solutions such as JETSTREAM,- and AEROWINGS. Achieve energy efficiency without compromising comfort with R32 refrigerant
Features
Powerful Cooling
Panasonic has accumulated many years of air conditioner technologies aimed at providing a comfortable space and optimal room temperature for everybody, wherever they are in the room. One of these, called JETSTREAM, achieves a maximum airflow length of 25 meters. This Long Reach Airflow brings clean, comfortable air to every corner of the room.
Large Air Intake
Large air intake draws in a large amount of air.
Large Diameter Fan
Large-diameter fan generates a stronger airflow.
AEROWINGS
The AEROWINGS feature combines a pair of wings to send air further.
Rapid Cooling at the click of a button
By pressing the JETSTREAM™ button on the remote control, you immediately get Rapid Cooling supported by the following three key factors
Eco-friendly R32 Refrigerant
Panasonic air conditioners have been increasingly adopting the eco-friendly R32 refrigerant. An excellent heat transfer medium for energy efficiency and cost savings. It also has low global warming potential, making it friendlier to the environment.
Long Piping Length
Industry No. 1 long piping length. 40m maximum pipe length. 30m maximum height difference.
60+ years of Manufacturing Experience.
Our R&D focuses on ease of use, and our history of rigorous quality control is unmatched in the industry. As a result, with more than 60+ years of experience, Panasonic has sold over 70 million air conditioner units in Japan and around the world.
Operating Test in Harsh Conditions
The operating noise of the indoor and outdoor units is measured in a high-performance anechoic chamber. The noise test verifies that the operating noise is low enough to allow the user to talk and sleep comfortably while the product is operating.
Environmental Test
An air conditioner is operated in a test room simulating a living room testing cooling speed, cooling efficiency, and temperature and humidity differences throughout the room.
Noise Test
The operating noise of the indoor and outdoor units is measured in a high-performance anechoic chamber. The noise test verifies that the operating noise is low enough to allow the user to talk and sleep comfortably while the product is operating.
Waterproof Test
Potential problems are checked by tests such as showering the unit for a predetermined amount of time. Contact sections on printed circuit boards are also resin-potted to prevent adverse effects caused by an unlikely exposure of droplets to water.
Specs
Size and Weight
- Height
- 309mm
- Width
- 1212mm
- Depth
- 269mm
- Weight
- 16kg
*Indoor Unit Dimensions
25 meters long air distance with JETSTREAM and the improved new AEROWINGS
Eco-friendly R32 Refrigerant
Industry No. 1 long piping length. 40m maximum pipe length. 30m maximum height difference.
Model#
-
CS/CU-YN30YKF
Type
-
Cool Only
Compressor
-
Fixed Speed, Rotary
Refrigerant
-
R32
Cooling Capacity (Btu/h) (T1/T3)
-
28200/24400
Heating Capacity (Btu/h) (T1/T3)
-
-
Electrical Data (T1/T3)
-
Voltage (V)
-
230-240
-
-
Running current (A)
-
10.4/12.6
-
-
Power input (W)
-
2340/2800
-
-
EER (Btu/hW) (T1/T3)
-
12.05/8.71
-
Pipe Extension (m)
-
Maximum Pipe Length
-
40
-
-
Maximum Height Difference
-
30
-
Operating (Ambient) Temperature
-
55°C
Net Dimension (IDU / ODU)
-
H x W x D (mm)
-
309 x 1212 x 269/695 x 875 x 320
-
Gross Dimension (IDU / ODU)
-
352 x 1300 x 403/783 x 1049 x 485
Net / Gross Weight (Kg)
-
IDU / ODU
-
16/51 (N)
19/56 (G)
-
Country of Origin
-
Malaysia
