CS-US9ZKD
Efficient Cooling, Ultimate Comfort
![](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2470216.jpg.pub.crop.pc.thumb.640.1200.jpg)
![](/etc/designs/panasonic/productpage-2-clientlibs/scene7/images/icn-spinicon.png)
![](/etc/designs/panasonic/productpage-2-clientlibs/scene7/images/icn-pinchzoom.png)
Features
Quick Cooling and Less Energy Consumption with Powerful Inverter Compressor
![Quick Cooling and Less Energy Consumption with Powerful Inverter Compressor](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467085.png.pub.thumb.644.644.png)
PM2.5 Filter
![PM2.5 Filter](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467086.jpg.pub.thumb.644.644.jpg)
Low Voltage Starter
![Low Voltage Starter](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467087.jpg.pub.thumb.644.644.jpg)
The Safest Refrigerant Gas
![The Safest Refrigerant Gas](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467088.png.pub.thumb.644.644.png)
65+ years of Manufacturing Experience.
![65+ years of Manufacturing Experience.](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467089.jpg.pub.thumb.644.644.jpg)
Operating Test in Harsh Conditions
![Operating Test in Harsh Conditions](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467091.jpg.pub.thumb.644.644.jpg)
Environmental Test
![Environmental Test](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467092.jpg.pub.thumb.644.644.jpg)
Noise Test
![Noise Test](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467093.jpg.pub.thumb.644.644.jpg)
Waterproof Test
![Waterproof Test](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2467096.jpg.pub.thumb.644.644.jpg)
Specs
![Photo of CS-US9ZKD, Split Air Conditioner](/content/dam/pim/mi/en/CS/CS-US9/CS-US9ZKD/ast-2476632.png.pub.thumb.644.644.png)
Size and Weight
- Height
- 200mm
- Width
- 750mm
- Depth
- 285mm
- Weight
- 8kg
*Note: Indoor Unit Dimensions
Inverter for Efficient and Quick Cooling
PM2.5 Filter
Low Voltage Starter
Type
-
Cool only/Inverter
Power Supply
-
V/Ph/Hz
-
220-240V~/50Hz
-
Cooling
-
Capacity
-
Btu/h
-
9000
-
-
W
-
2600
-
-
-
Rated Power Consumption
-
W
-
840
-
-
-
Rated Running Current
-
A
-
3.51
-
-
-
Max. Input Power
-
W
-
1500
-
-
-
Max. Input Current
-
A
-
8
-
-
-
EER Cooling
-
W/W
-
3.10
-
-
Air Flow Volume
-
m³/h
-
550
-
Indoor Unit
-
Dimension(W*D*H)
-
mm
-
750×285×200
-
-
-
Dimension cbm
-
m³
-
0.04275
-
-
-
Packing(W*D*H)
-
mm
-
820×347×277
-
-
-
Packing cbm
-
m³
-
0.07881758
-
-
-
Net Weight
-
kg
-
8
-
-
Outdoor Unit
-
Dimension(W*D*H)
-
mm
-
705×279×530
-
-
-
Dimension cbm
-
m³
-
0.10424835
-
-
-
Packing(W*D*H)
-
mm
-
825×345×595
-
-
-
Packing cbm
-
m³
-
0.169351875
-
-
-
Net Weight
-
kg
-
21
-
-
Refrigerant Type
-
R410a/kg
-
R410a/0.6kg
-
Connection(Stop Valve)
-
Gas Valve
-
Inches
-
Dg8(φ9.52)
-
-
-
Liquid Valve
-
Inches
-
Dg4(φ6.35)
-
-
Refrigerant Piping
-
Max refrigerant pipe length
-
m
-
7
-
-
-
Max difference in level
-
m
-
10
-
-
