CS-US24ZKD
Efficient Cooling, Ultimate Comfort
Experience quick cooling with Panasonic’s energy efficient Inverter Air Conditioner. Enjoy precise temperature control, healthier air quality, and reliable performance, all while saving energy and using eco-friendly refrigerant for a greener planet.
Features
Quick Cooling and Less Energy Consumption with Powerful Inverter Compressor
These air conditioners offer the flexibiliity to adjust the compressor’s rotation speed. This feature enables them to use less energy to maintain the set temperature, while also providing the capacity to cool under T3 Condition and heat the room faster upon start-up.
PM2.5 Filter
Effectively traps and inhibits PM2.5 pollutants in the air providing better and healthier air quality.
Low Voltage Starter
For stable operation during voltage fluctuation, the ‘US’ model’s inverter compressor with LVS operates with efficient working range 130V to 270V.
The Safest Refrigerant Gas
The R410A environment-friendly refrigerant contributes to greener planet as it has no harmful effects on the Ozone layer.
65+ years of Manufacturing Experience.
Our R&D focuses on ease of use, and our history of rigorous quality control is unmatched in the industry. As a result, with more than 60+ years of experience, Panasonic has sold over 70 million air conditioner units in Japan and around the world.
Operating Test in Harsh Conditions
The operating noise of the indoor and outdoor units is measured in a high-performance anechoic chamber. The noise test verifies that the operating noise is low enough to allow the user to talk and sleep comfortably while the product is operating.
Environmental Test
An air conditioner is operated in a test room simulating a living room testing cooling speed, cooling efficiency, and temperature and humidity differences throughout the room.
Noise Test
The operating noise of the indoor and outdoor units is measured in a high-performance anechoic chamber. The noise test verifies that the operating noise is low enough to allow the user to talk and sleep comfortably while the product is operating.
Waterproof Test
Potential problems are checked by tests such as showering the unit for a predetermined amount of time. Contact sections on printed circuit boards are also resin-potted to prevent adverse effects caused by an unlikely exposure of droplets to water.
Specs
Size and Weight
- Height
- 233mm
- Width
- 1082mm
- Depth
- 330mm
- Weight
- 13kg
*Note: Indoor Unit Dimensions
Inverter for Efficient and Quick Cooling
PM2.5 Filter
Low Voltage Starter
Type
-
Cool only/Inverter
Power Supply
-
V/Ph/Hz
-
220-240V~/50Hz
-
Cooling
-
Capacity
-
Btu/h
-
24000
-
-
W
-
6450
-
-
-
Rated Power Consumption
-
W
-
2150
-
-
-
Rated Running Current
-
A
-
9.1
-
-
-
Max. Input Power
-
W
-
3200
-
-
-
Max. Input Current
-
A
-
14
-
-
-
EER Cooling
-
W/W
-
3.00
-
-
Air Flow Volume
-
m³/h
-
1250
-
Indoor Unit
-
Dimension(W*D*H)
-
mm
-
1082×330×233
-
-
-
Dimension cbm
-
m³
-
0.08319498
-
-
-
Packing(W*D*H)
-
mm
-
1155×397×312
-
-
-
Packing cbm
-
m³
-
0.14306292
-
-
-
Net Weight
-
kg
-
13
-
-
Outdoor Unit
-
Dimension(W*D*H)
-
mm
-
825×655×310
-
-
-
Dimension cbm
-
m³
-
0.16751625
-
-
-
Packing(W*D*H)
-
mm
-
945×725×435
-
-
-
Packing cbm
-
m³
-
0.298029375
-
-
-
Net Weight
-
kg
-
36
-
-
Refrigerant Type
-
R410a/kg
-
R410a/0.95kg
-
Connection(Stop Valve)
-
Gas Valve
-
Inches
-
Dg13(φ15.88)
-
-
-
Liquid Valve
-
Inches
-
Dg4(φ6.35)
-
-
Refrigerant Piping
-
Max refrigerant pipe length
-
m
-
15
-
-
-
Max difference in level
-
m
-
15
-
-
