Cord-operated Shutter Series

FV-15WU4	220/50hz	Air Volume	210 m³/h 124 CFM
		Consumption [W]	8.1
		RPM [min^-1]	1,463
		Noise [dB(A)]	35
	220/60hz	Air Volume	200 m³/h 118 CFM
		Consumption [W]	8.9
		RPM [min^-1]	1,393
		Noise [dB(A)]	34
	230/50hz	Air Volume	220 m³/h 129 CFM
		Consumption [W]	8.8
		RPM [min^-1]	1,566
		Noise [dB(A)]	36
	240/50hz	Air Volume	230 m³/h 135 CFM
		Consumption [W]	9.5
		RPM [min^-1]	1,657
		Noise [dB(A)]	37
	Weight [kg]		0.9
	Installation Space [mm]		Ø186-Ø188
FV-20WU4	220/50hz	Air Volume	360 m³/h 212 CFM
		Consumption [W]	16.4
		RPM [min^-1]	1,042
		Noise [dB(A)]	32
	220/60hz	Air Volume	360 m³/h 212 CFM
		Consumption [W]	19
		RPM [min^-1]	1,024
		Noise [dB(A)]	31
	230/50hz	Air Volume	380 m³/h 224 CFM
		Consumption [W]	17.9
		RPM [min^-1]	1,122
		Noise [dB(A)]	34
	240/50hz	Air Volume	400 m³/h 235 CFM
		Consumption [W]	19.5
		RPM [min^-1]	1,189
		Noise [dB(A)]	36
	Weight [kg]		1.3
	Installation Space [mm]		Ø247-Ø250
Note			For info on test conditions, please refer to the technical sheet.
